BatteryClient Class Reference

batteryClient: The client side of any IBattery capable device. More...

#include <batteryClient/BatteryClient.h>

Inheritance diagram for BatteryClient:

Public Member Functions
bool	open (yarp::os::Searchable &config) override
	Open the DeviceDriver. More...
bool	close () override
	Close the DeviceDriver. More...
yarp::os::Stamp	getLastInputStamp () override
	Get the time stamp for the last read data. More...
bool	getBatteryVoltage (double &voltage) override
	Get the instantaneous voltage measurement. More...
bool	getBatteryCurrent (double &current) override
	Get the instantaneous current measurement. More...
bool	getBatteryCharge (double &charge) override
	get the battery status of charge More...
bool	getBatteryStatus (Battery_status &status) override
	get the battery status More...
bool	getBatteryInfo (std::string &battery_info) override
	get the battery hardware charactestics (e.g. More...
bool	getBatteryTemperature (double &temperature) override
	get the battery temperature More...
Public Member Functions inherited from yarp::dev::DeviceDriver
	~DeviceDriver () override=default
	Destructor. More...
template<class T >
bool	view (T *&x)
	Get an interface to the device driver. More...
virtual DeviceDriver *	getImplementation ()
	Some drivers are bureaucrats, pointing at others. More...
Public Member Functions inherited from yarp::os::IConfig
virtual	~IConfig ()
	Destructor. More...
virtual bool	configure (Searchable &config)
	Change online parameters. More...
Public Member Functions inherited from yarp::dev::IPreciselyTimed
virtual	~IPreciselyTimed ()
Public Member Functions inherited from yarp::dev::IBattery
virtual	~IBattery ()

Protected Attributes
BatteryInputPortProcessor	inputPort
yarp::os::Port	rpcPort
std::string	local
std::string	remote
yarp::os::Stamp	lastTs
std::string	deviceId

Additional Inherited Members
Public Types inherited from yarp::dev::IBattery
enum	Battery_status {   BATTERY_OK_STANBY = 0 ,   BATTERY_OK_IN_CHARGE = 1 ,   BATTERY_OK_IN_USE = 2 ,   BATTERY_GENERAL_ERROR = 3 ,   BATTERY_TIMEOUT = 4 ,   BATTERY_LOW_WARNING = 5 ,   BATTERY_CRITICAL_WARNING = 6 }

Detailed Description

batteryClient: The client side of any IBattery capable device.

Still single thread! concurrent access is unsafe.

Definition at line 71 of file BatteryClient.h.

Member Function Documentation

close()

bool BatteryClient::close ( )

overridevirtual

Close the DeviceDriver.

Returns

true/false on success/failure.

Reimplemented from yarp::dev::DeviceDriver.

Definition at line 233 of file BatteryClient.cpp.

getBatteryCharge()

bool BatteryClient::getBatteryCharge ( double &  charge )

overridevirtual

get the battery status of charge

Parameters

charge

the charge measurement (0-100%)

Returns

true/false.

Implements yarp::dev::IBattery.

Definition at line 252 of file BatteryClient.cpp.

getBatteryCurrent()

bool BatteryClient::getBatteryCurrent ( double &  current )

overridevirtual

Get the instantaneous current measurement.

Parameters

current

the current measurement

Returns

true/false.

Implements yarp::dev::IBattery.

Definition at line 246 of file BatteryClient.cpp.

getBatteryInfo()

bool BatteryClient::getBatteryInfo ( std::string &  battery_info )

overridevirtual

get the battery hardware charactestics (e.g.

max voltage etc)

Parameters

a	string containing the battery infos

Returns

true/false.

Implements yarp::dev::IBattery.

Definition at line 270 of file BatteryClient.cpp.

getBatteryStatus()

bool BatteryClient::getBatteryStatus ( Battery_status &  status )

overridevirtual

get the battery status

Parameters

status

the battery status

Returns

true/false.

Implements yarp::dev::IBattery.

Definition at line 258 of file BatteryClient.cpp.

getBatteryTemperature()

bool BatteryClient::getBatteryTemperature ( double &  temperature )

overridevirtual

get the battery temperature

Parameters

temprature

the battery temperature

Returns

true/false.

Implements yarp::dev::IBattery.

Definition at line 264 of file BatteryClient.cpp.

getBatteryVoltage()

bool BatteryClient::getBatteryVoltage ( double &  voltage )

overridevirtual

Get the instantaneous voltage measurement.

Parameters

voltage

the voltage measurement

Returns

true/false.

Implements yarp::dev::IBattery.

Definition at line 240 of file BatteryClient.cpp.

getLastInputStamp()

Stamp BatteryClient::getLastInputStamp ( )

overridevirtual

Get the time stamp for the last read data.

Returns

last time stamp.

Implements yarp::dev::IPreciselyTimed.

Definition at line 284 of file BatteryClient.cpp.

open()

bool BatteryClient::open ( yarp::os::Searchable &  config )

overridevirtual

Open the DeviceDriver.

Parameters

config

is a list of parameters for the device. Which parameters are effective for your device can vary. See device invocation examples. If there is no example for your device, you can run the "yarpdev" program with the verbose flag set to probe what parameters the device is checking. If that fails too, you'll need to read the source code (please nag one of the yarp developers to add documentation for your device).

Returns

true/false upon success/failure

Reimplemented from yarp::dev::DeviceDriver.

Definition at line 175 of file BatteryClient.cpp.

Member Data Documentation

deviceId

std::string BatteryClient::deviceId

protected

Definition at line 82 of file BatteryClient.h.

inputPort

BatteryInputPortProcessor BatteryClient::inputPort

protected

Definition at line 77 of file BatteryClient.h.

lastTs

yarp::os::Stamp BatteryClient::lastTs

protected

Definition at line 81 of file BatteryClient.h.

local

std::string BatteryClient::local

protected

Definition at line 79 of file BatteryClient.h.

remote

std::string BatteryClient::remote

protected

Definition at line 80 of file BatteryClient.h.

rpcPort

yarp::os::Port BatteryClient::rpcPort

protected

Definition at line 78 of file BatteryClient.h.

---

The documentation for this class was generated from the following files:

• src/devices/batteryClient/BatteryClient.h
• src/devices/batteryClient/BatteryClient.cpp
