#include <yarp/manager/localbroker.h>

Inheritance diagram for yarp::manager::LocalBroker:

Public Types
enum	WindowMode { WINDOW_HIDDEN =0 , WINDOW_VISIBLE =1 , WINDOW_MINIMIZED =2 }

Public Member Functions
	LocalBroker ()

virtual	~LocalBroker ()

bool	init () override

bool	init (const char szcmd, const char szparam, const char szhost, const char szstdio, const char szworkdir, const char szenv) override

void	fini () override

bool	start () override

bool	stop () override

bool	kill () override

bool	connect (const char from, const char to, const char *carrier, bool persist=false) override
	connection broker More...

bool	disconnect (const char from, const char to, const char *carrier) override

int	running () override

bool	exists (const char *port) override

const char *	requestRpc (const char szport, const char request, double timeout) override

bool	connected (const char from, const char to, const char *carrier) override

const char *	error () override

bool	initialized () override

bool	attachStdout () override

void	detachStdout () override

void	setWindowMode (WindowMode m)
	Define if the application will be visible or not. More...

void	run () override
	Main body of the new thread. More...

bool	threadInit () override
	Initialization method. More...

void	threadRelease () override
	Release method. More...

Public Member Functions inherited from yarp::manager::Broker
	Broker ()

virtual	~Broker ()

void	setEventSink (BrokerEventSink *pEventSink)

unsigned int	generateID ()

void	enableWatchDog ()

void	disableWatchDog ()

bool	hasWatchDog ()

void	setDisplay (const char *szDisplay)

const char *	getDisplay () const

Public Member Functions inherited from yarp::os::Thread
	Thread ()
	Constructor. More...

virtual	~Thread ()
	Destructor. More...

virtual void	onStop ()
	Call-back, called while halting the thread (before join). More...

bool	start ()
	Start the new thread running. More...

bool	stop ()
	Stop the thread. More...

virtual void	beforeStart ()
	Called just before a new thread starts. More...

virtual void	afterStart (bool success)
	Called just after a new thread starts (or fails to start), this is executed by the same thread that calls start(). More...

bool	isStopping ()
	Returns true if the thread is stopping (Thread::stop has been called). More...

bool	isRunning ()
	Returns true if the thread is running (Thread::start has been called successfully and the thread has not stopped). More...

long int	getKey ()
	Get a unique identifier for the thread. More...

int	setPriority (int priority, int policy=-1)
	Set the priority and scheduling policy of the thread, if the OS supports that. More...

int	getPriority ()
	Query the current priority of the thread, if the OS supports that. More...

int	getPolicy ()
	Query the current scheduling policy of the thread, if the OS supports that. More...

bool	join (double seconds=-1)
	The function returns when the thread execution has completed. More...

void	setOptions (int stackSize=0)
	Set the stack size for the new thread. More...

Additional Inherited Members
Static Public Member Functions inherited from yarp::os::Thread
static int	getCount ()
	Check how many threads are running. More...

static long int	getKeyOfCaller ()
	Get a unique identifier for the calling thread. More...

static void	yield ()
	Reschedule the execution of current thread, allowing other threads to run. More...

static void	setDefaultStackSize (int stackSize)
	Set the default stack size for all threads created after this point. More...

Protected Attributes inherited from yarp::manager::Broker
unsigned int	UNIQUEID

BrokerEventSink *	eventSink

bool	bWithWatchDog

std::string	strDisplay

Detailed Description

Class LocalBroker.

Definition at line 34 of file localbroker.h.

Member Enumeration Documentation

◆ WindowMode

enum yarp::manager::LocalBroker::WindowMode

Enumerator
WINDOW_HIDDEN
WINDOW_VISIBLE
WINDOW_MINIMIZED

Definition at line 38 of file localbroker.h.

Constructor & Destructor Documentation

◆ LocalBroker()

LocalBroker::LocalBroker ( )

Definition at line 140 of file localbroker.cpp.

◆ ~LocalBroker()

LocalBroker::~LocalBroker ( )

virtual

Definition at line 149 of file localbroker.cpp.

Member Function Documentation

◆ attachStdout()

bool LocalBroker::attachStdout ( )

overridevirtual

Implements yarp::manager::Broker.

Definition at line 509 of file localbroker.cpp.

◆ connect()

bool LocalBroker::connect	(	const char *	from,
		const char *	to,
		const char *	carrier,
		bool	persist = `false`
	)

overridevirtual

connection broker

Implements yarp::manager::Broker.

Definition at line 358 of file localbroker.cpp.

◆ connected()

bool LocalBroker::connected	(	const char *	from,
		const char *	to,
		const char *	carrier
	)

overridevirtual

Implements yarp::manager::Broker.

Definition at line 495 of file localbroker.cpp.

◆ detachStdout()

void LocalBroker::detachStdout ( )

overridevirtual

Implements yarp::manager::Broker.

Definition at line 522 of file localbroker.cpp.

◆ disconnect()

bool LocalBroker::disconnect	(	const char *	from,
		const char *	to,
		const char *	carrier
	)

overridevirtual

Implements yarp::manager::Broker.

Definition at line 398 of file localbroker.cpp.

◆ error()

const char * LocalBroker::error ( )

overridevirtual

Implements yarp::manager::Broker.

Definition at line 504 of file localbroker.cpp.

◆ exists()

bool LocalBroker::exists ( const char * port )

overridevirtual

Implements yarp::manager::Broker.

Definition at line 442 of file localbroker.cpp.

◆ fini()

void LocalBroker::fini ( )

overridevirtual

Implements yarp::manager::Broker.

Definition at line 154 of file localbroker.cpp.

◆ init() [1/2]

bool LocalBroker::init ( )

overridevirtual

Implements yarp::manager::Broker.

Reimplemented in yarp::manager::ScriptLocalBroker, and yarp::manager::ScriptLocalBroker.

Definition at line 161 of file localbroker.cpp.

◆ init() [2/2]

bool LocalBroker::init	(	const char *	szcmd,
		const char *	szparam,
		const char *	szhost,
		const char *	szstdio,
		const char *	szworkdir,
		const char *	szenv
	)

overridevirtual

Implements yarp::manager::Broker.

Reimplemented in yarp::manager::YarpdevLocalBroker, and yarp::manager::ScriptLocalBroker.

Definition at line 175 of file localbroker.cpp.

◆ initialized()

bool yarp::manager::LocalBroker::initialized ( )

inlineoverridevirtual

Implements yarp::manager::Broker.

Definition at line 64 of file localbroker.h.

◆ kill()

bool LocalBroker::kill ( )

overridevirtual

Implements yarp::manager::Broker.

Definition at line 308 of file localbroker.cpp.

◆ requestRpc()

const char * LocalBroker::requestRpc	(	const char *	szport,
		const char *	request,
		double	timeout
	)

overridevirtual

Implements yarp::manager::Broker.

Definition at line 448 of file localbroker.cpp.

◆ run()

void LocalBroker::run ( )

overridevirtual

Main body of the new thread.

Override this method to do what you want. After Thread::start is called, this method will start running in a separate thread. It is important that this method either keeps checking Thread::isStopping to see if it should stop, or you override the Thread::onStop method to interact with it in some way to shut the new thread down. There is no really reliable, portable way to stop a thread cleanly unless that thread cooperates.

Implements yarp::os::Thread.

Definition at line 543 of file localbroker.cpp.

◆ running()

int LocalBroker::running ( )

overridevirtual

Implements yarp::manager::Broker.

Definition at line 343 of file localbroker.cpp.

◆ setWindowMode()

void LocalBroker::setWindowMode ( WindowMode m )

Define if the application will be visible or not.

Definition at line 589 of file localbroker.cpp.

◆ start()

bool LocalBroker::start ( )

overridevirtual

Implements yarp::manager::Broker.

Definition at line 249 of file localbroker.cpp.

◆ stop()

bool LocalBroker::stop ( )

overridevirtual

Implements yarp::manager::Broker.

Definition at line 275 of file localbroker.cpp.

◆ threadInit()

bool LocalBroker::threadInit ( )

overridevirtual

Initialization method.

The thread executes this function when it starts and before "run". This is a good place to perform initialization tasks that need to be done by the thread itself (device drivers initialization, memory allocation etc). If the function returns false the thread quits and never calls "run". The return value of threadInit() is notified to the class and passed as a parameter to afterStart(). Note that afterStart() is called by the same thread that is executing the "start" method.

Reimplemented from yarp::os::Thread.

Definition at line 537 of file localbroker.cpp.

◆ threadRelease()

void LocalBroker::threadRelease ( )

overridevirtual

Release method.

The thread executes this function once when it exits, after the last "run". This is a good place to release resources that were initialized in threadInit() (release memory, and device driver resources).

Reimplemented from yarp::os::Thread.

Definition at line 584 of file localbroker.cpp.

The documentation for this class was generated from the following files:

src/libYARP_manager/src/yarp/manager/localbroker.h
src/libYARP_manager/src/yarp/manager/localbroker.cpp
