Public Types | Public Member Functions | Public Attributes | Static Public Attributes | List of all members
yarp::rosmsg::sensor_msgs::NavSatFix Class Reference

#include <yarp/rosmsg/sensor_msgs/NavSatFix.h>

+ Inheritance diagram for yarp::rosmsg::sensor_msgs::NavSatFix:

Public Types

typedef yarp::os::idl::BareStyle< yarp::rosmsg::sensor_msgs::NavSatFix > rosStyle

typedef yarp::os::idl::BottleStyle< yarp::rosmsg::sensor_msgs::NavSatFix > bottleStyle


Public Member Functions

 NavSatFix ()

void clear ()

bool readBare (yarp::os::ConnectionReader &connection) override

bool readBottle (yarp::os::ConnectionReader &connection) override

bool read (yarp::os::ConnectionReader &connection) override
 Read this object from a network connection. More...

bool writeBare (yarp::os::ConnectionWriter &connection) const override

bool writeBottle (yarp::os::ConnectionWriter &connection) const override

bool write (yarp::os::ConnectionWriter &connection) const override
 Write this object to a network connection. More...

yarp::os::Type getType () const override

- Public Member Functions inherited from yarp::os::idl::WirePortable
virtual bool read (yarp::os::idl::WireReader &reader)

virtual bool write (const yarp::os::idl::WireWriter &writer) const

- Public Member Functions inherited from yarp::os::PortReader
virtual ~PortReader ()
 Destructor. More...

virtual Type getReadType () const

- Public Member Functions inherited from yarp::os::PortWriter
virtual ~PortWriter ()
 Destructor. More...

virtual void onCompletion () const
 This is called when the port has finished all writing operations. More...

virtual void onCommencement () const
 This is called when the port is about to begin writing operations. More...

virtual yarp::os::Type getWriteType () const


Public Attributes

yarp::rosmsg::std_msgs::Header header

yarp::rosmsg::sensor_msgs::NavSatStatus status

yarp::conf::float64_t latitude

yarp::conf::float64_t longitude

yarp::conf::float64_t altitude

std::vector< yarp::conf::float64_t > position_covariance

std::uint8_t position_covariance_type


Static Public Attributes

static const std::uint8_t COVARIANCE_TYPE_UNKNOWN = 0

static const std::uint8_t COVARIANCE_TYPE_APPROXIMATED = 1

static const std::uint8_t COVARIANCE_TYPE_DIAGONAL_KNOWN = 2

static const std::uint8_t COVARIANCE_TYPE_KNOWN = 3

static constexpr const char * typeName = "sensor_msgs/NavSatFix"

static constexpr const char * typeChecksum = "2d3a8cd499b9b4a0249fb98fd05cfa48"

static constexpr const char * typeText


Additional Inherited Members

- Static Public Member Functions inherited from yarp::os::Portable
static bool copyPortable (const PortWriter &writer, PortReader &reader)
 Copy one portable to another, via writing and reading. More...


Detailed Description

Definition at line 73 of file NavSatFix.h.

Member Typedef Documentation

◆ bottleStyle

typedef yarp::os::idl::BottleStyle<yarp::rosmsg::sensor_msgs::NavSatFix> yarp::rosmsg::sensor_msgs::NavSatFix::bottleStyle

Definition at line 301 of file NavSatFix.h.

◆ rosStyle

typedef yarp::os::idl::BareStyle<yarp::rosmsg::sensor_msgs::NavSatFix> yarp::rosmsg::sensor_msgs::NavSatFix::rosStyle

Definition at line 300 of file NavSatFix.h.

Constructor & Destructor Documentation

◆ NavSatFix()

yarp::rosmsg::sensor_msgs::NavSatFix::NavSatFix ( )
inline

Definition at line 88 of file NavSatFix.h.

Member Function Documentation

◆ clear()

void yarp::rosmsg::sensor_msgs::NavSatFix::clear ( )
inline

Definition at line 100 of file NavSatFix.h.

◆ getType()

yarp::os::Type yarp::rosmsg::sensor_msgs::NavSatFix::getType ( ) const
inlineoverridevirtual

Reimplemented from yarp::os::Portable.

Definition at line 402 of file NavSatFix.h.

◆ read()

bool yarp::rosmsg::sensor_msgs::NavSatFix::read ( yarp::os::ConnectionReader &  reader)
inlineoverridevirtual

Read this object from a network connection.

Override this for your particular class.

Parameters
readeran interface to the network connection for reading
Returns
true iff the object is successfully read

Implements yarp::os::Portable.

Definition at line 211 of file NavSatFix.h.

◆ readBare()

bool yarp::rosmsg::sensor_msgs::NavSatFix::readBare ( yarp::os::ConnectionReader &  connection)
inlineoverridevirtual

Reimplemented from yarp::os::idl::WirePortable.

Definition at line 133 of file NavSatFix.h.

◆ readBottle()

bool yarp::rosmsg::sensor_msgs::NavSatFix::readBottle ( yarp::os::ConnectionReader &  connection)
inlineoverridevirtual

Reimplemented from yarp::os::idl::WirePortable.

Definition at line 167 of file NavSatFix.h.

◆ write()

bool yarp::rosmsg::sensor_msgs::NavSatFix::write ( yarp::os::ConnectionWriter &  writer) const
inlineoverridevirtual

Write this object to a network connection.

Override this for your particular class. Be aware that depending on the nature of the connections a port has, and what protocol they use, and how efficient the YARP implementation is, this method may be called once, twice, or many times, as the result of a single call to Port::write

Parameters
writeran interface to the network connection for writing
Returns
true iff the object is successfully written

Implements yarp::os::Portable.

Definition at line 292 of file NavSatFix.h.

◆ writeBare()

bool yarp::rosmsg::sensor_msgs::NavSatFix::writeBare ( yarp::os::ConnectionWriter &  connection) const
inlineoverridevirtual

Reimplemented from yarp::os::idl::WirePortable.

Definition at line 217 of file NavSatFix.h.

◆ writeBottle()

bool yarp::rosmsg::sensor_msgs::NavSatFix::writeBottle ( yarp::os::ConnectionWriter &  connection) const
inlineoverridevirtual

Reimplemented from yarp::os::idl::WirePortable.

Definition at line 249 of file NavSatFix.h.

Member Data Documentation

◆ altitude

yarp::conf::float64_t yarp::rosmsg::sensor_msgs::NavSatFix::altitude

Definition at line 80 of file NavSatFix.h.

◆ COVARIANCE_TYPE_APPROXIMATED

const std::uint8_t yarp::rosmsg::sensor_msgs::NavSatFix::COVARIANCE_TYPE_APPROXIMATED = 1
static

Definition at line 83 of file NavSatFix.h.

◆ COVARIANCE_TYPE_DIAGONAL_KNOWN

const std::uint8_t yarp::rosmsg::sensor_msgs::NavSatFix::COVARIANCE_TYPE_DIAGONAL_KNOWN = 2
static

Definition at line 84 of file NavSatFix.h.

◆ COVARIANCE_TYPE_KNOWN

const std::uint8_t yarp::rosmsg::sensor_msgs::NavSatFix::COVARIANCE_TYPE_KNOWN = 3
static

Definition at line 85 of file NavSatFix.h.

◆ COVARIANCE_TYPE_UNKNOWN

const std::uint8_t yarp::rosmsg::sensor_msgs::NavSatFix::COVARIANCE_TYPE_UNKNOWN = 0
static

Definition at line 82 of file NavSatFix.h.

◆ header

yarp::rosmsg::std_msgs::Header yarp::rosmsg::sensor_msgs::NavSatFix::header

Definition at line 76 of file NavSatFix.h.

◆ latitude

yarp::conf::float64_t yarp::rosmsg::sensor_msgs::NavSatFix::latitude

Definition at line 78 of file NavSatFix.h.

◆ longitude

yarp::conf::float64_t yarp::rosmsg::sensor_msgs::NavSatFix::longitude

Definition at line 79 of file NavSatFix.h.

◆ position_covariance

std::vector<yarp::conf::float64_t> yarp::rosmsg::sensor_msgs::NavSatFix::position_covariance

Definition at line 81 of file NavSatFix.h.

◆ position_covariance_type

std::uint8_t yarp::rosmsg::sensor_msgs::NavSatFix::position_covariance_type

Definition at line 86 of file NavSatFix.h.

◆ status

yarp::rosmsg::sensor_msgs::NavSatStatus yarp::rosmsg::sensor_msgs::NavSatFix::status

Definition at line 77 of file NavSatFix.h.

◆ typeChecksum

constexpr const char* yarp::rosmsg::sensor_msgs::NavSatFix::typeChecksum = "2d3a8cd499b9b4a0249fb98fd05cfa48"
staticconstexpr

Definition at line 307 of file NavSatFix.h.

◆ typeName

constexpr const char* yarp::rosmsg::sensor_msgs::NavSatFix::typeName = "sensor_msgs/NavSatFix"
staticconstexpr

Definition at line 304 of file NavSatFix.h.

◆ typeText

constexpr const char* yarp::rosmsg::sensor_msgs::NavSatFix::typeText
staticconstexpr

Definition at line 310 of file NavSatFix.h.

The documentation for this class was generated from the following file:
