batteryClient: The client side of any IBattery capable device. More...

#include <batteryClient/BatteryClient.h>

Inheritance diagram for BatteryClient:

Public Member Functions
bool	open (yarp::os::Searchable &config) override
	Open the DeviceDriver. More...

bool	close () override
	Close the DeviceDriver. More...

yarp::os::Stamp	getLastInputStamp () override
	Get the time stamp for the last read data. More...

bool	getBatteryVoltage (double &voltage) override
	Get the instantaneous voltage measurement. More...

bool	getBatteryCurrent (double &current) override
	Get the instantaneous current measurement. More...

bool	getBatteryCharge (double &charge) override
	get the battery status of charge More...

bool	getBatteryStatus (Battery_status &status) override
	get the battery status More...

bool	getBatteryInfo (std::string &battery_info) override
	get the battery hardware charactestics (e.g. More...

bool	getBatteryTemperature (double &temperature) override
	get the battery temperature More...

Public Member Functions inherited from yarp::dev::DeviceDriver
	DeviceDriver ()

	DeviceDriver (const DeviceDriver &other)=delete

	DeviceDriver (DeviceDriver &&other) noexcept=delete

DeviceDriver &	operator= (const DeviceDriver &other)=delete

DeviceDriver &	operator= (DeviceDriver &&other) noexcept=delete

	~DeviceDriver () override

bool	open (yarp::os::Searchable &config) override
	Open the DeviceDriver. More...

bool	close () override
	Close the DeviceDriver. More...

virtual std::string	id () const
	Return the id assigned to the PolyDriver. More...

virtual void	setId (const std::string &id)
	Set the id for this device. More...

template<class T >
bool	view (T *&x)
	Get an interface to the device driver. More...

virtual DeviceDriver *	getImplementation ()
	Some drivers are bureaucrats, pointing at others. More...

Public Member Functions inherited from yarp::os::IConfig
virtual	~IConfig ()
	Destructor. More...

virtual bool	open (Searchable &config)
	Initialize the object. More...

virtual bool	close ()
	Shut the object down. More...

virtual bool	configure (Searchable &config)
	Change online parameters. More...

Public Member Functions inherited from yarp::dev::IPreciselyTimed
virtual	~IPreciselyTimed ()

virtual yarp::os::Stamp	getLastInputStamp ()=0
	Return the time stamp relative to the last acquisition. More...

Public Member Functions inherited from yarp::dev::IBattery
virtual	~IBattery ()

virtual bool	getBatteryVoltage (double &voltage)=0
	Get the instantaneous voltage measurement. More...

virtual bool	getBatteryCurrent (double &current)=0
	Get the instantaneous current measurement. More...

virtual bool	getBatteryCharge (double &charge)=0
	get the battery status of charge More...

virtual bool	getBatteryStatus (Battery_status &status)=0
	get the battery status More...

virtual bool	getBatteryTemperature (double &temperature)=0
	get the battery temperature More...

virtual bool	getBatteryInfo (std::string &battery_info)=0
	get the battery hardware characteristics (e.g. More...

Protected Attributes
BatteryInputPortProcessor	inputPort

yarp::os::Port	rpcPort

std::string	local

std::string	remote

std::string	m_carrier

yarp::os::Stamp	lastTs

std::string	deviceId

Additional Inherited Members
Public Types inherited from yarp::dev::IBattery
enum	Battery_status { BATTERY_OK_STANBY = 0 , BATTERY_OK_IN_CHARGE = 1 , BATTERY_OK_IN_USE = 2 , BATTERY_GENERAL_ERROR = 3 , BATTERY_TIMEOUT = 4 , BATTERY_LOW_WARNING = 5 , BATTERY_CRITICAL_WARNING = 6 }

Detailed Description

batteryClient: The client side of any IBattery capable device.

Still single thread! concurrent access is unsafe.

Parameters required by this device are:

Parameter name	SubParameter	Type	Units	Default Value	Required	Description
local	-	string	-	-	Yes	Full port name opened by the batteryClient device.
remote	-	string	-	-	Yes	Full port name of the port opened on the server side, to which the batteryClient connects to.
carrier	-	string	-	tcp	No	The carier used for the connection with the server.

Definition at line 79 of file BatteryClient.h.

Member Function Documentation

◆ close()

bool BatteryClient::close ( )

overridevirtual

Close the DeviceDriver.

Returns: true/false on success/failure.

Reimplemented from yarp::dev::DeviceDriver.

Definition at line 234 of file BatteryClient.cpp.

◆ getBatteryCharge()

bool BatteryClient::getBatteryCharge ( double & charge )

overridevirtual

get the battery status of charge

Parameters

charge the charge measurement (0-100%)

Returns: true/false.

Implements yarp::dev::IBattery.

Definition at line 253 of file BatteryClient.cpp.

◆ getBatteryCurrent()

bool BatteryClient::getBatteryCurrent ( double & current )

overridevirtual

Get the instantaneous current measurement.

Parameters

current the current measurement

Returns: true/false.

Implements yarp::dev::IBattery.

Definition at line 247 of file BatteryClient.cpp.

◆ getBatteryInfo()

bool BatteryClient::getBatteryInfo ( std::string & battery_info )

overridevirtual

get the battery hardware charactestics (e.g.

max voltage etc)

Parameters

a	string containing the battery infos

Returns: true/false.

Implements yarp::dev::IBattery.

Definition at line 271 of file BatteryClient.cpp.

◆ getBatteryStatus()

bool BatteryClient::getBatteryStatus ( Battery_status & status )

overridevirtual

get the battery status

Parameters

status the battery status

Returns: true/false.

Implements yarp::dev::IBattery.

Definition at line 259 of file BatteryClient.cpp.

◆ getBatteryTemperature()

bool BatteryClient::getBatteryTemperature ( double & temperature )

overridevirtual

get the battery temperature

Parameters

temprature the battery temperature

Returns: true/false.

Implements yarp::dev::IBattery.

Definition at line 265 of file BatteryClient.cpp.

◆ getBatteryVoltage()

bool BatteryClient::getBatteryVoltage ( double & voltage )

overridevirtual

Get the instantaneous voltage measurement.

Parameters

voltage the voltage measurement

Returns: true/false.

Implements yarp::dev::IBattery.

Definition at line 241 of file BatteryClient.cpp.

◆ getLastInputStamp()

Stamp BatteryClient::getLastInputStamp ( )

overridevirtual

Get the time stamp for the last read data.

Returns: last time stamp.

Implements yarp::dev::IPreciselyTimed.

Definition at line 285 of file BatteryClient.cpp.

◆ open()

bool BatteryClient::open ( yarp::os::Searchable & config )

overridevirtual

Open the DeviceDriver.

Parameters

config is a list of parameters for the device. Which parameters are effective for your device can vary. See device invocation examples. If there is no example for your device, you can run the "yarpdev" program with the verbose flag set to probe what parameters the device is checking. If that fails too, you'll need to read the source code (please nag one of the yarp developers to add documentation for your device).

Returns: true/false upon success/failure

Reimplemented from yarp::dev::DeviceDriver.

Definition at line 175 of file BatteryClient.cpp.

Member Data Documentation

◆ deviceId

std::string BatteryClient::deviceId

protected

Definition at line 91 of file BatteryClient.h.

◆ inputPort

BatteryInputPortProcessor BatteryClient::inputPort

protected

Definition at line 85 of file BatteryClient.h.

◆ lastTs

yarp::os::Stamp BatteryClient::lastTs

protected

Definition at line 90 of file BatteryClient.h.

◆ local

std::string BatteryClient::local

protected

Definition at line 87 of file BatteryClient.h.

◆ m_carrier

std::string BatteryClient::m_carrier

protected

Definition at line 89 of file BatteryClient.h.

◆ remote

std::string BatteryClient::remote

protected

Definition at line 88 of file BatteryClient.h.

◆ rpcPort

yarp::os::Port BatteryClient::rpcPort

protected

Definition at line 86 of file BatteryClient.h.

The documentation for this class was generated from the following files:

src/devices/batteryClient/BatteryClient.h
src/devices/batteryClient/BatteryClient.cpp
