robotDescriptionClient: This client device is used to connect to a robotDescriptionServer and ask info about the currently opened devices. More...

#include <RobotDescriptionClient/RobotDescriptionClient.h>

Inheritance diagram for RobotDescriptionClient:

Public Member Functions
bool	open (yarp::os::Searchable &config) override
	Open the DeviceDriver. More...

bool	close () override
	Close the DeviceDriver. More...

bool	getAllDevices (std::vector< yarp::dev::DeviceDescription > &dev_list) override
	Ask the complete list of all yarp device drivers registered by a robot description server. More...

bool	getAllDevicesByType (const std::string &type, std::vector< yarp::dev::DeviceDescription > &dev_list) override
	Ask a list of all registered yarp device drivers whose type corresponds to the given param. More...

bool	registerDevice (const yarp::dev::DeviceDescription &dev) override
	Register a new running yarp device into a robot description server. More...

bool	unregisterDevice (const std::string &device_name) override
	Unregister a running yarp device from a robot description server. More...

Public Member Functions inherited from yarp::dev::DeviceDriver
	DeviceDriver ()

	DeviceDriver (const DeviceDriver &other)=delete

	DeviceDriver (DeviceDriver &&other) noexcept=delete

DeviceDriver &	operator= (const DeviceDriver &other)=delete

DeviceDriver &	operator= (DeviceDriver &&other) noexcept=delete

	~DeviceDriver () override

bool	open (yarp::os::Searchable &config) override
	Open the DeviceDriver. More...

bool	close () override
	Close the DeviceDriver. More...

virtual std::string	id () const
	Return the id assigned to the PolyDriver. More...

virtual void	setId (const std::string &id)
	Set the id for this device. More...

template<class T >
bool	view (T *&x)
	Get an interface to the device driver. More...

virtual DeviceDriver *	getImplementation ()
	Some drivers are bureaucrats, pointing at others. More...

Public Member Functions inherited from yarp::os::IConfig
virtual	~IConfig ()
	Destructor. More...

virtual bool	open (Searchable &config)
	Initialize the object. More...

virtual bool	close ()
	Shut the object down. More...

virtual bool	configure (Searchable &config)
	Change online parameters. More...

Public Member Functions inherited from yarp::dev::IRobotDescription
virtual	~IRobotDescription ()
	Destructor. More...

virtual bool	getAllDevices (std::vector< DeviceDescription > &dev_list)=0
	Ask the complete list of all yarp device drivers registered by a robot description server. More...

virtual bool	getAllDevicesByType (const std::string &type, std::vector< DeviceDescription > &dev_list)=0
	Ask a list of all registered yarp device drivers whose type corresponds to the given param. More...

virtual bool	registerDevice (const DeviceDescription &dev)=0
	Register a new running yarp device into a robot description server. More...

virtual bool	unregisterDevice (const std::string &device_name)=0
	Unregister a running yarp device from a robot description server. More...

Protected Attributes
std::mutex	m_mutex

yarp::os::Port	m_rpc_port

std::string	m_local_name

std::string	m_remote_name

Detailed Description

robotDescriptionClient: This client device is used to connect to a robotDescriptionServer and ask info about the currently opened devices.

Parameters required by this device are:

Parameter name	SubParameter	Type	Units	Default Value	Required	Description	Notes
local	-	string	-	-	Yes	prefix of the port opened by the device, like /my_module/descriptionClient	MUST start with a '/' character. /rpc is automatically appended.
remote	-	string	-	-	Yes	prefix of the port opened by the robotDescriptionServer, like /descriptionServer.	MUST start with a '/' character. /rpc is automatically appended.

Definition at line 33 of file RobotDescriptionClient.h.

Member Function Documentation

◆ close()

bool RobotDescriptionClient::close ( )

overridevirtual

Close the DeviceDriver.

Returns: true/false on success/failure.

Reimplemented from yarp::dev::DeviceDriver.

Definition at line 71 of file RobotDescriptionClient.cpp.

◆ getAllDevices()

bool RobotDescriptionClient::getAllDevices ( std::vector< yarp::dev::DeviceDescription > & dev_list )

overridevirtual

Ask the complete list of all yarp device drivers registered by a robot description server.

Implements yarp::dev::IRobotDescription.

Definition at line 170 of file RobotDescriptionClient.cpp.

◆ getAllDevicesByType()

bool RobotDescriptionClient::getAllDevicesByType	(	const std::string &	type,
		std::vector< yarp::dev::DeviceDescription > &	dev_list
	)

overridevirtual

Ask a list of all registered yarp device drivers whose type corresponds to the given param.

Implements yarp::dev::IRobotDescription.

Definition at line 78 of file RobotDescriptionClient.cpp.

◆ open()

bool RobotDescriptionClient::open ( yarp::os::Searchable & config )

overridevirtual

Open the DeviceDriver.

Parameters

config is a list of parameters for the device. Which parameters are effective for your device can vary. See device invocation examples. If there is no example for your device, you can run the "yarpdev" program with the verbose flag set to probe what parameters the device is checking. If that fails too, you'll need to read the source code (please nag one of the yarp developers to add documentation for your device).

Returns: true/false upon success/failure

Reimplemented from yarp::dev::DeviceDriver.

Definition at line 26 of file RobotDescriptionClient.cpp.

◆ registerDevice()

bool RobotDescriptionClient::registerDevice ( const yarp::dev::DeviceDescription & dev )

overridevirtual

Register a new running yarp device into a robot description server.

Implements yarp::dev::IRobotDescription.

Definition at line 143 of file RobotDescriptionClient.cpp.

◆ unregisterDevice()

bool RobotDescriptionClient::unregisterDevice ( const std::string & device_name )

overridevirtual

Unregister a running yarp device from a robot description server.

Implements yarp::dev::IRobotDescription.

Definition at line 117 of file RobotDescriptionClient.cpp.

Member Data Documentation

◆ m_local_name

std::string RobotDescriptionClient::m_local_name

protected

Definition at line 40 of file RobotDescriptionClient.h.

◆ m_mutex

std::mutex RobotDescriptionClient::m_mutex

protected

Definition at line 38 of file RobotDescriptionClient.h.

◆ m_remote_name

std::string RobotDescriptionClient::m_remote_name

protected

Definition at line 41 of file RobotDescriptionClient.h.

◆ m_rpc_port

yarp::os::Port RobotDescriptionClient::m_rpc_port

protected

Definition at line 39 of file RobotDescriptionClient.h.

The documentation for this class was generated from the following files:

src/devices/RobotDescriptionClient/RobotDescriptionClient.h
src/devices/RobotDescriptionClient/RobotDescriptionClient.cpp
