ServerSoundGrabber Class Reference

ServerSoundGrabber: Export a microphone device streaming sound samples More...

#include <ServerSoundGrabber/ServerSoundGrabber.h>

Inheritance diagram for ServerSoundGrabber:

Public Member Functions
	ServerSoundGrabber ()
	ServerSoundGrabber (const ServerSoundGrabber &)=delete
	ServerSoundGrabber (ServerSoundGrabber &&)=delete
ServerSoundGrabber &	operator= (const ServerSoundGrabber &)=delete
ServerSoundGrabber &	operator= (ServerSoundGrabber &&)=delete
	~ServerSoundGrabber () override
bool	open (yarp::os::Searchable &config) override
	Configure with a set of options. More...
bool	close () override
	Close the DeviceDriver. More...
void	run () override
	Main body of the new thread. More...
bool	read (yarp::os::ConnectionReader &connection) override
	Read this object from a network connection. More...
Public Member Functions inherited from yarp::dev::DeviceDriver
	DeviceDriver ()
	DeviceDriver (const DeviceDriver &other)=delete
	DeviceDriver (DeviceDriver &&other) noexcept=delete
DeviceDriver &	operator= (const DeviceDriver &other)=delete
DeviceDriver &	operator= (DeviceDriver &&other) noexcept=delete
	~DeviceDriver () override
bool	open (yarp::os::Searchable &config) override
	Open the DeviceDriver. More...
bool	close () override
	Close the DeviceDriver. More...
virtual std::string	id () const
	Return the id assigned to the PolyDriver. More...
virtual void	setId (const std::string &id)
	Set the id for this device. More...
template<class T >
bool	view (T *&x)
	Get an interface to the device driver. More...
virtual DeviceDriver *	getImplementation ()
	Some drivers are bureaucrats, pointing at others. More...
Public Member Functions inherited from yarp::os::IConfig
virtual	~IConfig ()
	Destructor. More...
virtual bool	open (Searchable &config)
	Initialize the object. More...
virtual bool	close ()
	Shut the object down. More...
virtual bool	configure (Searchable &config)
	Change online parameters. More...
Public Member Functions inherited from yarp::os::PortReader
virtual	~PortReader ()
	Destructor. More...
virtual bool	read (ConnectionReader &reader)=0
	Read this object from a network connection. More...
virtual Type	getReadType () const

Detailed Description

ServerSoundGrabber: Export a microphone device streaming sound samples

Definition at line 24 of file ServerSoundGrabber.h.

Constructor & Destructor Documentation

ServerSoundGrabber() [1/3]

ServerSoundGrabber::ServerSoundGrabber

(

)

Definition at line 22 of file ServerSoundGrabber.cpp.

ServerSoundGrabber() [2/3]

ServerSoundGrabber::ServerSoundGrabber ( const ServerSoundGrabber &  )

delete

ServerSoundGrabber() [3/3]

ServerSoundGrabber::ServerSoundGrabber ( ServerSoundGrabber &&  )

delete

~ServerSoundGrabber()

ServerSoundGrabber::~ServerSoundGrabber ( )

override

Definition at line 29 of file ServerSoundGrabber.cpp.

Member Function Documentation

close()

bool ServerSoundGrabber::close ( )

overridevirtual

Close the DeviceDriver.

Returns

true/false on success/failure.

Reimplemented from yarp::dev::DeviceDriver.

Definition at line 103 of file ServerSoundGrabber.cpp.

open()

bool ServerSoundGrabber::open ( yarp::os::Searchable &  config )

overridevirtual

Configure with a set of options.

These are:

subdevice	Common name of device to wrap (e.g. "fakeFrameGrabber").
name	Port name to assign to this server (default /grabber).

Parameters

config

The options to use

Returns

true iff the object could be configured.

Reimplemented from yarp::dev::DeviceDriver.

Definition at line 46 of file ServerSoundGrabber.cpp.

operator=() [1/2]

ServerSoundGrabber & ServerSoundGrabber::operator= ( const ServerSoundGrabber &  )

delete

operator=() [2/2]

ServerSoundGrabber & ServerSoundGrabber::operator= ( ServerSoundGrabber &&  )

delete

read()

bool ServerSoundGrabber::read ( yarp::os::ConnectionReader &  reader )

overridevirtual

Read this object from a network connection.

Override this for your particular class.

Parameters

reader

an interface to the network connection for reading

Returns

true iff the object is successfully read

Implements yarp::os::PortReader.

Definition at line 161 of file ServerSoundGrabber.cpp.

run()

void ServerSoundGrabber::run ( )

overridevirtual

Main body of the new thread.

Override this method to do what you want. After Thread::start is called, this method will start running in a separate thread. It is important that this method either keeps checking Thread::isStopping to see if it should stop, or you override the Thread::onStop method to interact with it in some way to shut the new thread down. There is no really reliable, portable way to stop a thread cleanly unless that thread cooperates.

Implements yarp::os::Thread.

Definition at line 119 of file ServerSoundGrabber.cpp.

---

The documentation for this class was generated from the following files:

• src/devices/ServerSoundGrabber/ServerSoundGrabber.h
• src/devices/ServerSoundGrabber/ServerSoundGrabber.cpp
