fakeMicrophone : fake microphone device implementing the IAudioGrabberSound interface to generate a test sound. More...

#include <fakeMicrophone/fakeMicrophone.h>

Inheritance diagram for fakeMicrophone:

Public Member Functions
	fakeMicrophone ()

	fakeMicrophone (const fakeMicrophone &)=delete

	fakeMicrophone (fakeMicrophone &&)=delete

fakeMicrophone &	operator= (const fakeMicrophone &)=delete

fakeMicrophone &	operator= (fakeMicrophone &&)=delete

	~fakeMicrophone () override

bool	setHWGain (double gain) override
	Sets the hardware gain of the grabbing device (if supported by the hardware) More...

bool	open (yarp::os::Searchable &config) override
	Open the DeviceDriver. More...

bool	close () override
	Close the DeviceDriver. More...

Public Member Functions inherited from yarp::dev::DeviceDriver
	DeviceDriver ()

	DeviceDriver (const DeviceDriver &other)=delete

	DeviceDriver (DeviceDriver &&other) noexcept=delete

DeviceDriver &	operator= (const DeviceDriver &other)=delete

DeviceDriver &	operator= (DeviceDriver &&other) noexcept=delete

	~DeviceDriver () override

bool	open (yarp::os::Searchable &config) override
	Open the DeviceDriver. More...

bool	close () override
	Close the DeviceDriver. More...

virtual std::string	id () const
	Return the id assigned to the PolyDriver. More...

virtual void	setId (const std::string &id)
	Set the id for this device. More...

template<class T >
bool	view (T *&x)
	Get an interface to the device driver. More...

virtual DeviceDriver *	getImplementation ()
	Some drivers are bureaucrats, pointing at others. More...

Public Member Functions inherited from yarp::os::IConfig
virtual	~IConfig ()
	Destructor. More...

virtual bool	open (Searchable &config)
	Initialize the object. More...

virtual bool	close ()
	Shut the object down. More...

virtual bool	configure (Searchable &config)
	Change online parameters. More...

Public Member Functions inherited from yarp::dev::AudioRecorderDeviceBase
virtual bool	getSound (yarp::sig::Sound &sound, size_t min_number_of_samples, size_t max_number_of_samples, double max_samples_timeout_s) override
	Get a sound from a device. More...

virtual bool	startRecording () override
	Start the recording. More...

virtual bool	stopRecording () override
	Stop the recording. More...

virtual bool	isRecording (bool &recording_enabled) override
	Check if the recording has been enabled (e.g. More...

virtual bool	getRecordingAudioBufferMaxSize (yarp::dev::AudioBufferSize &size) override

virtual bool	getRecordingAudioBufferCurrentSize (yarp::dev::AudioBufferSize &size) override

virtual bool	resetRecordingAudioBuffer () override

virtual bool	setSWGain (double gain) override
	Sets a software gain for the grabbed audio. More...

virtual	~AudioRecorderDeviceBase ()

Public Member Functions inherited from yarp::dev::IAudioGrabberSound
virtual	~IAudioGrabberSound ()
	Destructor. More...

virtual bool	getSound (yarp::sig::Sound &sound, size_t min_number_of_samples, size_t max_number_of_samples, double max_samples_timeout_s)=0
	Get a sound from a device. More...

virtual bool	startRecording ()=0
	Start the recording. More...

virtual bool	stopRecording ()=0
	Stop the recording. More...

virtual bool	isRecording (bool &recording_enabled)=0
	Check if the recording has been enabled (e.g. More...

virtual bool	getRecordingAudioBufferMaxSize (yarp::dev::AudioBufferSize &size)=0

virtual bool	getRecordingAudioBufferCurrentSize (yarp::dev::AudioBufferSize &size)=0

virtual bool	resetRecordingAudioBuffer ()=0

virtual bool	setSWGain (double gain)=0
	Sets a software gain for the grabbed audio. More...

virtual bool	setHWGain (double gain)=0
	Sets the hardware gain of the grabbing device (if supported by the hardware) More...

Public Member Functions inherited from yarp::os::PeriodicThread
	PeriodicThread (double period, ShouldUseSystemClock useSystemClock=ShouldUseSystemClock::No, PeriodicThreadClock clockAccuracy=PeriodicThreadClock::Relative)
	Constructor. More...

	PeriodicThread (double period, PeriodicThreadClock clockAccuracy)
	Constructor. More...

virtual	~PeriodicThread ()

bool	start ()
	Call this to start the thread. More...

void	step ()
	Call this to "step" the thread rather than starting it. More...

void	stop ()
	Call this to stop the thread, this call blocks until the thread is terminated (and releaseThread() called). More...

void	askToStop ()
	Stop the thread. More...

bool	isRunning () const
	Returns true when the thread is started, false otherwise. More...

bool	isSuspended () const
	Returns true when the thread is suspended, false otherwise. More...

bool	setPeriod (double period)
	Set the (new) period of the thread. More...

double	getPeriod () const
	Return the current period of the thread. More...

void	suspend ()
	Suspend the thread, the thread keeps running by doLoop is never executed. More...

void	resume ()
	Resume the thread if previously suspended. More...

void	resetStat ()
	Reset thread statistics. More...

double	getEstimatedPeriod () const
	Return estimated period since last reset. More...

void	getEstimatedPeriod (double &av, double &std) const
	Return estimated period since last reset. More...

unsigned int	getIterations () const
	Return the number of iterations performed since last reset. More...

double	getEstimatedUsed () const
	Return the estimated duration of the run() function since last reset. More...

void	getEstimatedUsed (double &av, double &std) const
	Return estimated duration of the run() function since last reset. More...

int	setPriority (int priority, int policy=-1)
	Set the priority and scheduling policy of the thread, if the OS supports that. More...

int	getPriority () const
	Query the current priority of the thread, if the OS supports that. More...

int	getPolicy () const
	Query the current scheduling policy of the thread, if the OS supports that. More...

Additional Inherited Members
Protected Member Functions inherited from yarp::dev::AudioRecorderDeviceBase
bool	configureRecorderAudioDevice (yarp::os::Searchable &config, std::string device_name)

Protected Member Functions inherited from yarp::os::PeriodicThread
virtual bool	threadInit ()
	Initialization method. More...

virtual void	threadRelease ()
	Release method. More...

virtual void	run ()=0
	Loop function. More...

virtual void	beforeStart ()
	Called just before a new thread starts. More...

virtual void	afterStart (bool success)
	Called just after a new thread starts (or fails to start), this is executed by the same thread that calls start(). More...

Protected Attributes inherited from yarp::dev::AudioRecorderDeviceBase
bool	m_enable_buffer_autoclear = false

bool	m_recording_enabled = false

std::mutex	m_mutex

yarp::dev::CircularAudioBuffer_16t *	m_inputBuffer = nullptr

double	m_sw_gain = 1.0

double	m_hw_gain = 1.0

AudioDeviceDriverSettings	m_audiorecorder_cfg

bool	m_audiobase_debug = false

int16_t	m_cliptol = 3

Detailed Description

fakeMicrophone : fake microphone device implementing the IAudioGrabberSound interface to generate a test sound.

It can generate various signals, i.e. sine, sawtooth, square wave, constant. This device driver derives from AudioRecorderDeviceBase base class. Please check its documentation for additional details.

Parameters used by this device are:

Parameter name	SubParameter	Type	Units	Default Value	Required	Description	Notes
AUDIO_BASE	***		-	-	No	For the documentation of AUDIO_BASE group, please refer to the documentation of the base class AudioRecorderDeviceBase
period	-	double	s	0.010	No	the period of processing thread	A value of 10ms is recommended. Do to not modify it
waveform	-	string	-	sine	No	Defines the shape of the waveform. Can be one of the following: sine,sawtooth,square,constant	-
signal_frequency	-	int	Hz	440	No	Frequency of the generated signal	-
signal_amplitude	-	int		32000	No	Amplitude of the generated signal	-
driver_frame_size	-	int	samples	512	No	the number of samples to process on each iteration of the thread	-

See Audio in YARP for additional documentation on YARP audio.

Definition at line 36 of file fakeMicrophone.h.

Constructor & Destructor Documentation

◆ fakeMicrophone() [1/3]

fakeMicrophone::fakeMicrophone ( )

Definition at line 33 of file fakeMicrophone.cpp.

◆ fakeMicrophone() [2/3]

fakeMicrophone::fakeMicrophone ( const fakeMicrophone & )

delete

◆ fakeMicrophone() [3/3]

fakeMicrophone::fakeMicrophone ( fakeMicrophone && )

delete

◆ ~fakeMicrophone()

fakeMicrophone::~fakeMicrophone ( )

override

Definition at line 38 of file fakeMicrophone.cpp.

Member Function Documentation

◆ close()

bool fakeMicrophone::close ( )

overridevirtual

Close the DeviceDriver.

Returns: true/false on success/failure.

Reimplemented from yarp::dev::DeviceDriver.

Definition at line 118 of file fakeMicrophone.cpp.

◆ open()

bool fakeMicrophone::open ( yarp::os::Searchable & config )

overridevirtual

Open the DeviceDriver.

Parameters

config is a list of parameters for the device. Which parameters are effective for your device can vary. See device invocation examples. If there is no example for your device, you can run the "yarpdev" program with the verbose flag set to probe what parameters the device is checking. If that fails too, you'll need to read the source code (please nag one of the yarp developers to add documentation for your device).

Returns: true/false upon success/failure

Reimplemented from yarp::dev::DeviceDriver.

Definition at line 43 of file fakeMicrophone.cpp.

◆ operator=() [1/2]

fakeMicrophone & fakeMicrophone::operator= ( const fakeMicrophone & )

delete

◆ operator=() [2/2]

fakeMicrophone & fakeMicrophone::operator= ( fakeMicrophone && )

delete

◆ setHWGain()

bool fakeMicrophone::setHWGain ( double gain )

overridevirtual

Sets the hardware gain of the grabbing device (if supported by the hardware)

Parameters

gain	the audio gain (1.0 is the default value)

Returns: true/false upon success/failure

Implements yarp::dev::IAudioGrabberSound.

Definition at line 127 of file fakeMicrophone.cpp.

The documentation for this class was generated from the following files:

src/devices/fakeMicrophone/fakeMicrophone.h
src/devices/fakeMicrophone/fakeMicrophone.cpp
