fakeSpeaker : fake device implementing the IAudioRender device interface to play sound More...

#include <fakeSpeaker/fakeSpeaker.h>

Inheritance diagram for fakeSpeaker:

Public Member Functions
	fakeSpeaker ()

	fakeSpeaker (const fakeSpeaker &)=delete

	fakeSpeaker (fakeSpeaker &&)=delete

fakeSpeaker &	operator= (const fakeSpeaker &)=delete

fakeSpeaker &	operator= (fakeSpeaker &&)=delete

	~fakeSpeaker () override

bool	open (yarp::os::Searchable &config) override
	Open the DeviceDriver. More...

bool	close () override
	Close the DeviceDriver. More...

virtual bool	setHWGain (double gain) override
	Sets the hardware gain of the playback device (if supported by the hardware) More...

virtual bool	configureDeviceAndStart () override

virtual bool	interruptDeviceAndClose () override

Public Member Functions inherited from yarp::dev::DeviceDriver
	DeviceDriver ()

	DeviceDriver (const DeviceDriver &other)=delete

	DeviceDriver (DeviceDriver &&other) noexcept=delete

DeviceDriver &	operator= (const DeviceDriver &other)=delete

DeviceDriver &	operator= (DeviceDriver &&other) noexcept=delete

	~DeviceDriver () override

bool	open (yarp::os::Searchable &config) override
	Open the DeviceDriver. More...

bool	close () override
	Close the DeviceDriver. More...

virtual std::string	id () const
	Return the id assigned to the PolyDriver. More...

virtual void	setId (const std::string &id)
	Set the id for this device. More...

template<class T >
bool	view (T *&x)
	Get an interface to the device driver. More...

virtual DeviceDriver *	getImplementation ()
	Some drivers are bureaucrats, pointing at others. More...

Public Member Functions inherited from yarp::os::IConfig
virtual	~IConfig ()
	Destructor. More...

virtual bool	open (Searchable &config)
	Initialize the object. More...

virtual bool	close ()
	Shut the object down. More...

virtual bool	configure (Searchable &config)
	Change online parameters. More...

Public Member Functions inherited from yarp::dev::AudioPlayerDeviceBase
virtual bool	renderSound (const yarp::sig::Sound &sound) override
	Render a sound using a device (i.e. More...

virtual bool	startPlayback () override
	Start the playback. More...

virtual bool	stopPlayback () override
	Stop the playback. More...

virtual bool	isPlaying (bool &playback_enabled) override
	Check if the playback has been enabled (e.g. More...

virtual bool	getPlaybackAudioBufferMaxSize (yarp::dev::AudioBufferSize &size) override

virtual bool	getPlaybackAudioBufferCurrentSize (yarp::dev::AudioBufferSize &size) override

virtual bool	resetPlaybackAudioBuffer () override

virtual bool	setSWGain (double gain) override
	Sets a software gain for the played audio. More...

virtual	~AudioPlayerDeviceBase ()

Public Member Functions inherited from yarp::dev::IAudioRender
virtual	~IAudioRender ()
	Destructor. More...

virtual bool	renderSound (const yarp::sig::Sound &sound)=0
	Render a sound using a device (i.e. More...

virtual bool	startPlayback ()=0
	Start the playback. More...

virtual bool	stopPlayback ()=0
	Stop the playback. More...

virtual bool	isPlaying (bool &playback_enabled)=0
	Check if the playback has been enabled (e.g. More...

virtual bool	getPlaybackAudioBufferMaxSize (yarp::dev::AudioBufferSize &size)=0

virtual bool	getPlaybackAudioBufferCurrentSize (yarp::dev::AudioBufferSize &size)=0

virtual bool	resetPlaybackAudioBuffer ()=0

virtual bool	setSWGain (double gain)=0
	Sets a software gain for the played audio. More...

virtual bool	setHWGain (double gain)=0
	Sets the hardware gain of the playback device (if supported by the hardware) More...

Public Member Functions inherited from yarp::os::PeriodicThread
	PeriodicThread (double period, ShouldUseSystemClock useSystemClock=ShouldUseSystemClock::No, PeriodicThreadClock clockAccuracy=PeriodicThreadClock::Relative)
	Constructor. More...

	PeriodicThread (double period, PeriodicThreadClock clockAccuracy)
	Constructor. More...

virtual	~PeriodicThread ()

bool	start ()
	Call this to start the thread. More...

void	step ()
	Call this to "step" the thread rather than starting it. More...

void	stop ()
	Call this to stop the thread, this call blocks until the thread is terminated (and releaseThread() called). More...

void	askToStop ()
	Stop the thread. More...

bool	isRunning () const
	Returns true when the thread is started, false otherwise. More...

bool	isSuspended () const
	Returns true when the thread is suspended, false otherwise. More...

bool	setPeriod (double period)
	Set the (new) period of the thread. More...

double	getPeriod () const
	Return the current period of the thread. More...

void	suspend ()
	Suspend the thread, the thread keeps running by doLoop is never executed. More...

void	resume ()
	Resume the thread if previously suspended. More...

void	resetStat ()
	Reset thread statistics. More...

double	getEstimatedPeriod () const
	Return estimated period since last reset. More...

void	getEstimatedPeriod (double &av, double &std) const
	Return estimated period since last reset. More...

unsigned int	getIterations () const
	Return the number of iterations performed since last reset. More...

double	getEstimatedUsed () const
	Return the estimated duration of the run() function since last reset. More...

void	getEstimatedUsed (double &av, double &std) const
	Return estimated duration of the run() function since last reset. More...

int	setPriority (int priority, int policy=-1)
	Set the priority and scheduling policy of the thread, if the OS supports that. More...

int	getPriority () const
	Query the current priority of the thread, if the OS supports that. More...

int	getPolicy () const
	Query the current scheduling policy of the thread, if the OS supports that. More...

Additional Inherited Members
Protected Types inherited from yarp::dev::AudioPlayerDeviceBase
enum	{ RENDER_APPEND = 0 , RENDER_IMMEDIATE = 1 }

Protected Member Functions inherited from yarp::dev::AudioPlayerDeviceBase
virtual bool	configureDeviceAndStart ()=0

virtual bool	interruptDeviceAndClose ()=0

virtual void	waitUntilPlaybackStreamIsComplete ()

virtual bool	immediateSound (const yarp::sig::Sound &sound)

virtual bool	appendSound (const yarp::sig::Sound &sound)

bool	configurePlayerAudioDevice (yarp::os::Searchable &config, std::string device_name)

Protected Member Functions inherited from yarp::os::PeriodicThread
virtual bool	threadInit ()
	Initialization method. More...

virtual void	threadRelease ()
	Release method. More...

virtual void	run ()=0
	Loop function. More...

virtual void	beforeStart ()
	Called just before a new thread starts. More...

virtual void	afterStart (bool success)
	Called just after a new thread starts (or fails to start), this is executed by the same thread that calls start(). More...

Protected Attributes inherited from yarp::dev::AudioPlayerDeviceBase
bool	m_enable_buffer_autoclear = false

bool	m_playback_enabled = false

std::recursive_mutex	m_mutex

yarp::dev::CircularAudioBuffer_16t *	m_outputBuffer = nullptr

AudioDeviceDriverSettings	m_audioplayer_cfg

double	m_sw_gain = 1.0

double	m_hw_gain = 1.0

bool	m_audiobase_debug = false

enum yarp::dev::AudioPlayerDeviceBase:: { ... }	m_renderMode = RENDER_APPEND

Detailed Description

fakeSpeaker : fake device implementing the IAudioRender device interface to play sound

This device driver derives from AudioPlayerDeviceBase base class. Please check its documentation for additional details.

Parameters used by this device are:

Parameter name	SubParameter	Type	Units	Default Value	Required	Description	Notes
AUDIO_BASE	***		-	-	No	For the documentation of AUDIO_BASE group, please refer to the documentation of the base class AudioPlayerDeviceBase
period	-	double	s	0.010	No	the period of processing thread	A value of 10ms is recommended. Do to not modify it

See Audio in YARP for additional documentation on YARP audio.

Definition at line 32 of file fakeSpeaker.h.

Constructor & Destructor Documentation

◆ fakeSpeaker() [1/3]

fakeSpeaker::fakeSpeaker ( )

Definition at line 28 of file fakeSpeaker.cpp.

◆ fakeSpeaker() [2/3]

fakeSpeaker::fakeSpeaker ( const fakeSpeaker & )

delete

◆ fakeSpeaker() [3/3]

fakeSpeaker::fakeSpeaker ( fakeSpeaker && )

delete

◆ ~fakeSpeaker()

fakeSpeaker::~fakeSpeaker ( )

override

Definition at line 33 of file fakeSpeaker.cpp.

Member Function Documentation

◆ close()

bool fakeSpeaker::close ( )

overridevirtual

Close the DeviceDriver.

Returns: true/false on success/failure.

Reimplemented from yarp::dev::DeviceDriver.

Definition at line 68 of file fakeSpeaker.cpp.

◆ configureDeviceAndStart()

bool fakeSpeaker::configureDeviceAndStart ( )

overridevirtual

Implements yarp::dev::AudioPlayerDeviceBase.

Definition at line 128 of file fakeSpeaker.cpp.

◆ interruptDeviceAndClose()

bool fakeSpeaker::interruptDeviceAndClose ( )

overridevirtual

Implements yarp::dev::AudioPlayerDeviceBase.

Definition at line 134 of file fakeSpeaker.cpp.

◆ open()

bool fakeSpeaker::open ( yarp::os::Searchable & config )

overridevirtual

Open the DeviceDriver.

Parameters

config is a list of parameters for the device. Which parameters are effective for your device can vary. See device invocation examples. If there is no example for your device, you can run the "yarpdev" program with the verbose flag set to probe what parameters the device is checking. If that fails too, you'll need to read the source code (please nag one of the yarp developers to add documentation for your device).

Returns: true/false upon success/failure

Reimplemented from yarp::dev::DeviceDriver.

Definition at line 38 of file fakeSpeaker.cpp.

◆ operator=() [1/2]

fakeSpeaker & fakeSpeaker::operator= ( const fakeSpeaker & )

delete

◆ operator=() [2/2]

fakeSpeaker & fakeSpeaker::operator= ( fakeSpeaker && )

delete

◆ setHWGain()

bool fakeSpeaker::setHWGain ( double gain )

overridevirtual

Sets the hardware gain of the playback device (if supported by the hardware)

Parameters

gain	the audio gain (1.0 is the default value)

Returns: true/false upon success/failure

Implements yarp::dev::IAudioRender.

Definition at line 117 of file fakeSpeaker.cpp.

The documentation for this class was generated from the following files:

src/devices/fakeSpeaker/fakeSpeaker.h
src/devices/fakeSpeaker/fakeSpeaker.cpp
