yarp::proto::framegrabber::FrameGrabberControlsDC1394_Forwarder Class Reference

#include <framegrabber_protocol/yarp/proto/framegrabber/FrameGrabberControlsDC1394_Forwarder.h>

+ Inheritance diagram for yarp::proto::framegrabber::FrameGrabberControlsDC1394_Forwarder:

Public Member Functions

 FrameGrabberControlsDC1394_Forwarder (yarp::os::Port &port)

 ~FrameGrabberControlsDC1394_Forwarder () override=default

unsigned int getVideoModeMaskDC1394 () override

unsigned int getVideoModeDC1394 () override

bool setVideoModeDC1394 (int video_mode) override

unsigned int getFPSMaskDC1394 () override

unsigned int getFPSDC1394 () override

bool setFPSDC1394 (int fps) override

unsigned int getISOSpeedDC1394 () override

bool setISOSpeedDC1394 (int speed) override

unsigned int getColorCodingMaskDC1394 (unsigned int video_mode) override

unsigned int getColorCodingDC1394 () override

bool setColorCodingDC1394 (int coding) override

bool getFormat7MaxWindowDC1394 (unsigned int &xdim, unsigned int &ydim, unsigned int &xstep, unsigned int &ystep, unsigned int &xoffstep, unsigned int &yoffstep) override

bool getFormat7WindowDC1394 (unsigned int &xdim, unsigned int &ydim, int &x0, int &y0) override

bool setFormat7WindowDC1394 (unsigned int xdim, unsigned int ydim, int x0, int y0) override

bool setOperationModeDC1394 (bool b1394b) override

bool getOperationModeDC1394 () override

bool setTransmissionDC1394 (bool bTxON) override

bool getTransmissionDC1394 () override

bool setBroadcastDC1394 (bool onoff) override

bool setDefaultsDC1394 () override

bool setResetDC1394 () override

bool setPowerDC1394 (bool onoff) override

bool setCaptureDC1394 (bool bON) override

bool setBytesPerPacketDC1394 (unsigned int bpp) override

unsigned int getBytesPerPacketDC1394 () override

- Public Member Functions inherited from yarp::dev::IFrameGrabberControlsDC1394
virtual ~IFrameGrabberControlsDC1394 ()

virtual unsigned int getVideoModeMaskDC1394 ()=0

virtual unsigned int getVideoModeDC1394 ()=0

virtual bool setVideoModeDC1394 (int video_mode)=0

virtual unsigned int getFPSMaskDC1394 ()=0

virtual unsigned int getFPSDC1394 ()=0

virtual bool setFPSDC1394 (int fps)=0

virtual unsigned int getISOSpeedDC1394 ()=0

virtual bool setISOSpeedDC1394 (int speed)=0

virtual unsigned int getColorCodingMaskDC1394 (unsigned int video_mode)=0

virtual unsigned int getColorCodingDC1394 ()=0

virtual bool setColorCodingDC1394 (int coding)=0

virtual bool getFormat7MaxWindowDC1394 (unsigned int &xdim, unsigned int &ydim, unsigned int &xstep, unsigned int &ystep, unsigned int &xoffstep, unsigned int &yoffstep)=0

virtual bool getFormat7WindowDC1394 (unsigned int &xdim, unsigned int &ydim, int &x0, int &y0)=0

virtual bool setFormat7WindowDC1394 (unsigned int xdim, unsigned int ydim, int x0, int y0)=0

virtual bool setOperationModeDC1394 (bool b1394b)=0

virtual bool getOperationModeDC1394 ()=0

virtual bool setTransmissionDC1394 (bool bTxON)=0

virtual bool getTransmissionDC1394 ()=0

virtual bool setBroadcastDC1394 (bool onoff)=0

virtual bool setDefaultsDC1394 ()=0

virtual bool setResetDC1394 ()=0

virtual bool setPowerDC1394 (bool onoff)=0

virtual bool setCaptureDC1394 (bool bON)=0

virtual unsigned int getBytesPerPacketDC1394 ()=0

virtual bool setBytesPerPacketDC1394 (unsigned int bpp)=0


Detailed Description

Definition at line 15 of file FrameGrabberControlsDC1394_Forwarder.h.

Constructor & Destructor Documentation

◆ FrameGrabberControlsDC1394_Forwarder()

FrameGrabberControlsDC1394_Forwarder::FrameGrabberControlsDC1394_Forwarder ( yarp::os::Port &  port)

Definition at line 14 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ ~FrameGrabberControlsDC1394_Forwarder()

yarp::proto::framegrabber::FrameGrabberControlsDC1394_Forwarder::~FrameGrabberControlsDC1394_Forwarder ( )
overridedefault

Member Function Documentation

◆ getBytesPerPacketDC1394()

unsigned int FrameGrabberControlsDC1394_Forwarder::getBytesPerPacketDC1394 ( )
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 370 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ getColorCodingDC1394()

unsigned int FrameGrabberControlsDC1394_Forwarder::getColorCodingDC1394 ( )
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 178 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ getColorCodingMaskDC1394()

unsigned int FrameGrabberControlsDC1394_Forwarder::getColorCodingMaskDC1394 ( unsigned int  video_mode)
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 166 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ getFormat7MaxWindowDC1394()

bool FrameGrabberControlsDC1394_Forwarder::getFormat7MaxWindowDC1394 ( unsigned int &  xdim,
unsigned int &  ydim,
unsigned int &  xstep,
unsigned int &  ystep,
unsigned int &  xoffstep,
unsigned int &  yoffstep
)
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 201 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ getFormat7WindowDC1394()

bool FrameGrabberControlsDC1394_Forwarder::getFormat7WindowDC1394 ( unsigned int &  xdim,
unsigned int &  ydim,
int &  x0,
int &  y0
)
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 224 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ getFPSDC1394()

unsigned int FrameGrabberControlsDC1394_Forwarder::getFPSDC1394 ( )
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 120 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ getFPSMaskDC1394()

unsigned int FrameGrabberControlsDC1394_Forwarder::getFPSMaskDC1394 ( )
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 109 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ getISOSpeedDC1394()

unsigned int FrameGrabberControlsDC1394_Forwarder::getISOSpeedDC1394 ( )
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 143 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ getOperationModeDC1394()

bool FrameGrabberControlsDC1394_Forwarder::getOperationModeDC1394 ( )
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 266 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ getTransmissionDC1394()

bool FrameGrabberControlsDC1394_Forwarder::getTransmissionDC1394 ( )
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 289 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ getVideoModeDC1394()

unsigned int FrameGrabberControlsDC1394_Forwarder::getVideoModeDC1394 ( )
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 86 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ getVideoModeMaskDC1394()

unsigned int FrameGrabberControlsDC1394_Forwarder::getVideoModeMaskDC1394 ( )
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 75 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ setBroadcastDC1394()

bool FrameGrabberControlsDC1394_Forwarder::setBroadcastDC1394 ( bool  onoff)
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 300 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ setBytesPerPacketDC1394()

bool FrameGrabberControlsDC1394_Forwarder::setBytesPerPacketDC1394 ( unsigned int  bpp)
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 358 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ setCaptureDC1394()

bool FrameGrabberControlsDC1394_Forwarder::setCaptureDC1394 ( bool  bON)
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 346 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ setColorCodingDC1394()

bool FrameGrabberControlsDC1394_Forwarder::setColorCodingDC1394 ( int  coding)
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 189 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ setDefaultsDC1394()

bool FrameGrabberControlsDC1394_Forwarder::setDefaultsDC1394 ( )
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 312 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ setFormat7WindowDC1394()

bool FrameGrabberControlsDC1394_Forwarder::setFormat7WindowDC1394 ( unsigned int  xdim,
unsigned int  ydim,
int  x0,
int  y0
)
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 239 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ setFPSDC1394()

bool FrameGrabberControlsDC1394_Forwarder::setFPSDC1394 ( int  fps)
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 131 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ setISOSpeedDC1394()

bool FrameGrabberControlsDC1394_Forwarder::setISOSpeedDC1394 ( int  speed)
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 154 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ setOperationModeDC1394()

bool FrameGrabberControlsDC1394_Forwarder::setOperationModeDC1394 ( bool  b1394b)
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 254 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ setPowerDC1394()

bool FrameGrabberControlsDC1394_Forwarder::setPowerDC1394 ( bool  onoff)
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 334 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ setResetDC1394()

bool FrameGrabberControlsDC1394_Forwarder::setResetDC1394 ( )
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 323 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ setTransmissionDC1394()

bool FrameGrabberControlsDC1394_Forwarder::setTransmissionDC1394 ( bool  bTxON)
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 277 of file FrameGrabberControlsDC1394_Forwarder.cpp.

◆ setVideoModeDC1394()

bool FrameGrabberControlsDC1394_Forwarder::setVideoModeDC1394 ( int  video_mode)
overridevirtual

Implements yarp::dev::IFrameGrabberControlsDC1394.

Definition at line 97 of file FrameGrabberControlsDC1394_Forwarder.cpp.

The documentation for this class was generated from the following files:
