YARP
Yet Another Robot Platform
Public Types | Public Member Functions | Public Attributes | Static Public Attributes | List of all members
yarp::rosmsg::diagnostic_msgs::KeyValue Class Reference

#include <yarp/rosmsg/diagnostic_msgs/KeyValue.h>

+ Inheritance diagram for yarp::rosmsg::diagnostic_msgs::KeyValue:

Public Types

typedef yarp::os::idl::BareStyle< yarp::rosmsg::diagnostic_msgs::KeyValue > rosStyle

typedef yarp::os::idl::BottleStyle< yarp::rosmsg::diagnostic_msgs::KeyValue > bottleStyle


Public Member Functions

 KeyValue ()

void clear ()

bool readBare (yarp::os::ConnectionReader &connection) override

bool readBottle (yarp::os::ConnectionReader &connection) override

bool read (yarp::os::ConnectionReader &connection) override
 Read this object from a network connection. More...

bool writeBare (yarp::os::ConnectionWriter &connection) const override

bool writeBottle (yarp::os::ConnectionWriter &connection) const override

bool write (yarp::os::ConnectionWriter &connection) const override
 Write this object to a network connection. More...

yarp::os::Type getType () const override

- Public Member Functions inherited from yarp::os::idl::WirePortable
virtual bool read (yarp::os::idl::WireReader &reader)

virtual bool write (const yarp::os::idl::WireWriter &writer) const

virtual bool readBare (yarp::os::ConnectionReader &reader)

virtual bool writeBare (yarp::os::ConnectionWriter &writer) const

virtual bool readBottle (yarp::os::ConnectionReader &reader)

virtual bool writeBottle (yarp::os::ConnectionWriter &writer) const

bool read (ConnectionReader &reader) override=0
 Read this object from a network connection. More...

bool write (ConnectionWriter &writer) const override=0
 Write this object to a network connection. More...

virtual Type getType () const

- Public Member Functions inherited from yarp::os::PortReader
virtual ~PortReader ()
 Destructor. More...

virtual bool read (ConnectionReader &reader)=0
 Read this object from a network connection. More...

virtual Type getReadType () const

- Public Member Functions inherited from yarp::os::PortWriter
virtual ~PortWriter ()
 Destructor. More...

virtual bool write (ConnectionWriter &writer) const =0
 Write this object to a network connection. More...

virtual void onCompletion () const
 This is called when the port has finished all writing operations. More...

virtual void onCommencement () const
 This is called when the port is about to begin writing operations. More...

virtual yarp::os::Type getWriteType () const


Public Attributes

std::string key

std::string value


Static Public Attributes

static constexpr const char * typeName = "diagnostic_msgs/KeyValue"

static constexpr const char * typeChecksum = "cf57fdc6617a881a88c16e768132149c"

static constexpr const char * typeText


Additional Inherited Members

- Static Public Member Functions inherited from yarp::os::Portable
static bool copyPortable (const PortWriter &writer, PortReader &reader)
 Copy one portable to another, via writing and reading. More...


Detailed Description

Definition at line 27 of file KeyValue.h.

Member Typedef Documentation

◆ bottleStyle

typedef yarp::os::idl::BottleStyle<yarp::rosmsg::diagnostic_msgs::KeyValue> yarp::rosmsg::diagnostic_msgs::KeyValue::bottleStyle

Definition at line 137 of file KeyValue.h.

◆ rosStyle

typedef yarp::os::idl::BareStyle<yarp::rosmsg::diagnostic_msgs::KeyValue> yarp::rosmsg::diagnostic_msgs::KeyValue::rosStyle

Definition at line 136 of file KeyValue.h.

Constructor & Destructor Documentation

◆ KeyValue()

yarp::rosmsg::diagnostic_msgs::KeyValue::KeyValue ( )
inline

Definition at line 33 of file KeyValue.h.

Member Function Documentation

◆ clear()

void yarp::rosmsg::diagnostic_msgs::KeyValue::clear ( )
inline

Definition at line 39 of file KeyValue.h.

◆ getType()

yarp::os::Type yarp::rosmsg::diagnostic_msgs::KeyValue::getType ( ) const
inlineoverridevirtual

Reimplemented from yarp::os::Portable.

Definition at line 151 of file KeyValue.h.

◆ read()

bool yarp::rosmsg::diagnostic_msgs::KeyValue::read ( yarp::os::ConnectionReader &  reader)
inlineoverridevirtual

Read this object from a network connection.

Override this for your particular class.

Parameters
readeran interface to the network connection for reading
Returns
true iff the object is successfully read

Implements yarp::os::Portable.

Definition at line 89 of file KeyValue.h.

◆ readBare()

bool yarp::rosmsg::diagnostic_msgs::KeyValue::readBare ( yarp::os::ConnectionReader &  connection)
inlineoverridevirtual

Reimplemented from yarp::os::idl::WirePortable.

Definition at line 48 of file KeyValue.h.

◆ readBottle()

bool yarp::rosmsg::diagnostic_msgs::KeyValue::readBottle ( yarp::os::ConnectionReader &  connection)
inlineoverridevirtual

Reimplemented from yarp::os::idl::WirePortable.

Definition at line 67 of file KeyValue.h.

◆ write()

bool yarp::rosmsg::diagnostic_msgs::KeyValue::write ( yarp::os::ConnectionWriter &  writer) const
inlineoverridevirtual

Write this object to a network connection.

Override this for your particular class. Be aware that depending on the nature of the connections a port has, and what protocol they use, and how efficient the YARP implementation is, this method may be called once, twice, or many times, as the result of a single call to Port::write

Parameters
writeran interface to the network connection for writing
Returns
true iff the object is successfully written

Implements yarp::os::Portable.

Definition at line 128 of file KeyValue.h.

◆ writeBare()

bool yarp::rosmsg::diagnostic_msgs::KeyValue::writeBare ( yarp::os::ConnectionWriter &  connection) const
inlineoverridevirtual

Reimplemented from yarp::os::idl::WirePortable.

Definition at line 95 of file KeyValue.h.

◆ writeBottle()

bool yarp::rosmsg::diagnostic_msgs::KeyValue::writeBottle ( yarp::os::ConnectionWriter &  connection) const
inlineoverridevirtual

Reimplemented from yarp::os::idl::WirePortable.

Definition at line 108 of file KeyValue.h.

Member Data Documentation

◆ key

std::string yarp::rosmsg::diagnostic_msgs::KeyValue::key

Definition at line 30 of file KeyValue.h.

◆ typeChecksum

constexpr const char* yarp::rosmsg::diagnostic_msgs::KeyValue::typeChecksum = "cf57fdc6617a881a88c16e768132149c"
staticconstexpr

Definition at line 143 of file KeyValue.h.

◆ typeName

constexpr const char* yarp::rosmsg::diagnostic_msgs::KeyValue::typeName = "diagnostic_msgs/KeyValue"
staticconstexpr

Definition at line 140 of file KeyValue.h.

◆ typeText

constexpr const char* yarp::rosmsg::diagnostic_msgs::KeyValue::typeText
staticconstexpr
Initial value:
= "\
string key # what to label this value when viewing\n\
string value # a value to track over time\n\
"

Definition at line 146 of file KeyValue.h.

◆ value

std::string yarp::rosmsg::diagnostic_msgs::KeyValue::value

Definition at line 31 of file KeyValue.h.

The documentation for this class was generated from the following file:
