#include <yarp/rosmsg/shape_msgs/SolidPrimitive.h>

Inheritance diagram for yarp::rosmsg::shape_msgs::SolidPrimitive:

Public Types
typedef yarp::os::idl::BareStyle< yarp::rosmsg::shape_msgs::SolidPrimitive >	rosStyle

typedef yarp::os::idl::BottleStyle< yarp::rosmsg::shape_msgs::SolidPrimitive >	bottleStyle

Public Member Functions
	SolidPrimitive ()

void	clear ()

bool	readBare (yarp::os::ConnectionReader &connection) override

bool	readBottle (yarp::os::ConnectionReader &connection) override

bool	read (yarp::os::ConnectionReader &connection) override
	Read this object from a network connection. More...

bool	writeBare (yarp::os::ConnectionWriter &connection) const override

bool	writeBottle (yarp::os::ConnectionWriter &connection) const override

bool	write (yarp::os::ConnectionWriter &connection) const override
	Write this object to a network connection. More...

yarp::os::Type	getType () const override

Public Member Functions inherited from yarp::os::idl::WirePortable
virtual bool	read (yarp::os::idl::WireReader &reader)

virtual bool	write (const yarp::os::idl::WireWriter &writer) const

virtual bool	readBare (yarp::os::ConnectionReader &reader)

virtual bool	writeBare (yarp::os::ConnectionWriter &writer) const

virtual bool	readBottle (yarp::os::ConnectionReader &reader)

virtual bool	writeBottle (yarp::os::ConnectionWriter &writer) const

bool	read (ConnectionReader &reader) override=0
	Read this object from a network connection. More...

bool	write (ConnectionWriter &writer) const override=0
	Write this object to a network connection. More...

virtual Type	getType () const

Public Member Functions inherited from yarp::os::PortReader
virtual	~PortReader ()
	Destructor. More...

virtual bool	read (ConnectionReader &reader)=0
	Read this object from a network connection. More...

virtual Type	getReadType () const

Public Member Functions inherited from yarp::os::PortWriter
virtual	~PortWriter ()
	Destructor. More...

virtual bool	write (ConnectionWriter &writer) const =0
	Write this object to a network connection. More...

virtual void	onCompletion () const
	This is called when the port has finished all writing operations. More...

virtual void	onCommencement () const
	This is called when the port is about to begin writing operations. More...

virtual yarp::os::Type	getWriteType () const

Public Attributes
std::uint8_t	type

std::vector< yarp::conf::float64_t >	dimensions

Static Public Attributes
static const std::uint8_t	BOX = 1

static const std::uint8_t	SPHERE = 2

static const std::uint8_t	CYLINDER = 3

static const std::uint8_t	CONE = 4

static const std::uint8_t	BOX_X = 0

static const std::uint8_t	BOX_Y = 1

static const std::uint8_t	BOX_Z = 2

static const std::uint8_t	SPHERE_RADIUS = 0

static const std::uint8_t	CYLINDER_HEIGHT = 0

static const std::uint8_t	CYLINDER_RADIUS = 1

static const std::uint8_t	CONE_HEIGHT = 0

static const std::uint8_t	CONE_RADIUS = 1

static constexpr const char *	typeName = "shape_msgs/SolidPrimitive"

static constexpr const char *	typeChecksum = "d8f8cbc74c5ff283fca29569ccefb45d"

static constexpr const char *	typeText

Additional Inherited Members
Static Public Member Functions inherited from yarp::os::Portable
static bool	copyPortable (const PortWriter &writer, PortReader &reader)
	Copy one portable to another, via writing and reading. More...

Detailed Description

Definition at line 67 of file SolidPrimitive.h.

Member Typedef Documentation

◆ bottleStyle

typedef yarp::os::idl::BottleStyle<yarp::rosmsg::shape_msgs::SolidPrimitive> yarp::rosmsg::shape_msgs::SolidPrimitive::bottleStyle

Definition at line 214 of file SolidPrimitive.h.

◆ rosStyle

typedef yarp::os::idl::BareStyle<yarp::rosmsg::shape_msgs::SolidPrimitive> yarp::rosmsg::shape_msgs::SolidPrimitive::rosStyle

Definition at line 213 of file SolidPrimitive.h.

Constructor & Destructor Documentation

◆ SolidPrimitive()

yarp::rosmsg::shape_msgs::SolidPrimitive::SolidPrimitive ( )

inline

Definition at line 85 of file SolidPrimitive.h.

Member Function Documentation

◆ clear()

void yarp::rosmsg::shape_msgs::SolidPrimitive::clear ( )

inline

Definition at line 91 of file SolidPrimitive.h.

◆ getType()

yarp::os::Type yarp::rosmsg::shape_msgs::SolidPrimitive::getType ( ) const

inlineoverridevirtual

Reimplemented from yarp::os::Portable.

Definition at line 268 of file SolidPrimitive.h.

◆ read()

bool yarp::rosmsg::shape_msgs::SolidPrimitive::read ( yarp::os::ConnectionReader & reader )

inlineoverridevirtual

Read this object from a network connection.

Override this for your particular class.

Parameters

reader an interface to the network connection for reading

Returns: true iff the object is successfully read

Implements yarp::os::Portable.

Definition at line 164 of file SolidPrimitive.h.

◆ readBare()

bool yarp::rosmsg::shape_msgs::SolidPrimitive::readBare ( yarp::os::ConnectionReader & connection )

inlineoverridevirtual

Reimplemented from yarp::os::idl::WirePortable.

Definition at line 124 of file SolidPrimitive.h.

◆ readBottle()

bool yarp::rosmsg::shape_msgs::SolidPrimitive::readBottle ( yarp::os::ConnectionReader & connection )

inlineoverridevirtual

Reimplemented from yarp::os::idl::WirePortable.

Definition at line 139 of file SolidPrimitive.h.

◆ write()

bool yarp::rosmsg::shape_msgs::SolidPrimitive::write ( yarp::os::ConnectionWriter & writer ) const

inlineoverridevirtual

Write this object to a network connection.

Override this for your particular class. Be aware that depending on the nature of the connections a port has, and what protocol they use, and how efficient the YARP implementation is, this method may be called once, twice, or many times, as the result of a single call to Port::write

Parameters

writer an interface to the network connection for writing

Returns: true iff the object is successfully written

Implements yarp::os::Portable.

Definition at line 205 of file SolidPrimitive.h.

◆ writeBare()

bool yarp::rosmsg::shape_msgs::SolidPrimitive::writeBare ( yarp::os::ConnectionWriter & connection ) const

inlineoverridevirtual

Reimplemented from yarp::os::idl::WirePortable.

Definition at line 170 of file SolidPrimitive.h.

◆ writeBottle()

bool yarp::rosmsg::shape_msgs::SolidPrimitive::writeBottle ( yarp::os::ConnectionWriter & connection ) const

inlineoverridevirtual

Reimplemented from yarp::os::idl::WirePortable.

Definition at line 184 of file SolidPrimitive.h.

Member Data Documentation

◆ BOX

const std::uint8_t yarp::rosmsg::shape_msgs::SolidPrimitive::BOX = 1

static

Definition at line 70 of file SolidPrimitive.h.

◆ BOX_X

const std::uint8_t yarp::rosmsg::shape_msgs::SolidPrimitive::BOX_X = 0

static

Definition at line 76 of file SolidPrimitive.h.

◆ BOX_Y

const std::uint8_t yarp::rosmsg::shape_msgs::SolidPrimitive::BOX_Y = 1

static

Definition at line 77 of file SolidPrimitive.h.

◆ BOX_Z

const std::uint8_t yarp::rosmsg::shape_msgs::SolidPrimitive::BOX_Z = 2

static

Definition at line 78 of file SolidPrimitive.h.

◆ CONE

const std::uint8_t yarp::rosmsg::shape_msgs::SolidPrimitive::CONE = 4

static

Definition at line 73 of file SolidPrimitive.h.

◆ CONE_HEIGHT

const std::uint8_t yarp::rosmsg::shape_msgs::SolidPrimitive::CONE_HEIGHT = 0

static

Definition at line 82 of file SolidPrimitive.h.

◆ CONE_RADIUS

const std::uint8_t yarp::rosmsg::shape_msgs::SolidPrimitive::CONE_RADIUS = 1

static

Definition at line 83 of file SolidPrimitive.h.

◆ CYLINDER

const std::uint8_t yarp::rosmsg::shape_msgs::SolidPrimitive::CYLINDER = 3

static

Definition at line 72 of file SolidPrimitive.h.

◆ CYLINDER_HEIGHT

const std::uint8_t yarp::rosmsg::shape_msgs::SolidPrimitive::CYLINDER_HEIGHT = 0

static

Definition at line 80 of file SolidPrimitive.h.

◆ CYLINDER_RADIUS

const std::uint8_t yarp::rosmsg::shape_msgs::SolidPrimitive::CYLINDER_RADIUS = 1

static

Definition at line 81 of file SolidPrimitive.h.

◆ dimensions

std::vector<yarp::conf::float64_t> yarp::rosmsg::shape_msgs::SolidPrimitive::dimensions

Definition at line 75 of file SolidPrimitive.h.

◆ SPHERE

const std::uint8_t yarp::rosmsg::shape_msgs::SolidPrimitive::SPHERE = 2

static

Definition at line 71 of file SolidPrimitive.h.

◆ SPHERE_RADIUS

const std::uint8_t yarp::rosmsg::shape_msgs::SolidPrimitive::SPHERE_RADIUS = 0

static

Definition at line 79 of file SolidPrimitive.h.

◆ type

std::uint8_t yarp::rosmsg::shape_msgs::SolidPrimitive::type

Definition at line 74 of file SolidPrimitive.h.

◆ typeChecksum

constexpr const char* yarp::rosmsg::shape_msgs::SolidPrimitive::typeChecksum = "d8f8cbc74c5ff283fca29569ccefb45d"

staticconstexpr

Definition at line 220 of file SolidPrimitive.h.

◆ typeName

constexpr const char* yarp::rosmsg::shape_msgs::SolidPrimitive::typeName = "shape_msgs/SolidPrimitive"

staticconstexpr

Definition at line 217 of file SolidPrimitive.h.

◆ typeText

constexpr const char* yarp::rosmsg::shape_msgs::SolidPrimitive::typeText

staticconstexpr

Definition at line 223 of file SolidPrimitive.h.

The documentation for this class was generated from the following file:

src/libYARP_rosmsg/src/idl_generated_code/yarp/rosmsg/shape_msgs/SolidPrimitive.h
