yarp::dev::AudioRecorderStatus Class Reference

AudioRecorderStatus: A class used to describe the status of an audio recorder device. More...

#include <yarp/dev/AudioRecorderStatus.h>

+ Inheritance diagram for yarp::dev::AudioRecorderStatus:

Classes

class  Editor


Public Types

typedef yarp::os::idl::Unwrapped< AudioRecorderStatus > unwrapped


Public Member Functions

 AudioRecorderStatus ()

 AudioRecorderStatus (const bool enabled, const size_t current_buffer_size, const size_t max_buffer_size)

bool read (yarp::os::idl::WireReader &reader) override

bool read (yarp::os::ConnectionReader &connection) override
 Read this object from a network connection. More...

bool write (const yarp::os::idl::WireWriter &writer) const override

bool write (yarp::os::ConnectionWriter &connection) const override
 Write this object to a network connection. More...

std::string toString () const

- Public Member Functions inherited from yarp::os::idl::WirePortable
virtual bool readBare (yarp::os::ConnectionReader &reader)

virtual bool writeBare (yarp::os::ConnectionWriter &writer) const

virtual bool readBottle (yarp::os::ConnectionReader &reader)

virtual bool writeBottle (yarp::os::ConnectionWriter &writer) const

- Public Member Functions inherited from yarp::os::Portable
virtual Type getType () const

- Public Member Functions inherited from yarp::os::PortReader
virtual ~PortReader ()
 Destructor. More...

virtual Type getReadType () const

- Public Member Functions inherited from yarp::os::PortWriter
virtual ~PortWriter ()
 Destructor. More...

virtual void onCompletion () const
 This is called when the port has finished all writing operations. More...

virtual void onCommencement () const
 This is called when the port is about to begin writing operations. More...

virtual yarp::os::Type getWriteType () const


Public Attributes

bool enabled
 true if the playback is currently enabled More...

size_t current_buffer_size
 the size of the audio buffer [samples] More...

size_t max_buffer_size
 the max_size of the audio buffer [samples] More...


Additional Inherited Members

- Static Public Member Functions inherited from yarp::os::Portable
static bool copyPortable (const PortWriter &writer, PortReader &reader)
 Copy one portable to another, via writing and reading. More...


Detailed Description

AudioRecorderStatus: A class used to describe the status of an audio recorder device.

See Audio in YARP for additional documentation on YARP audio.

Definition at line 28 of file AudioRecorderStatus.h.

Member Typedef Documentation

◆ unwrapped

typedef yarp::os::idl::Unwrapped<AudioRecorderStatus> yarp::dev::AudioRecorderStatus::unwrapped

Definition at line 70 of file AudioRecorderStatus.h.

Constructor & Destructor Documentation

◆ AudioRecorderStatus() [1/2]

yarp::dev::AudioRecorderStatus::AudioRecorderStatus ( )

Definition at line 17 of file AudioRecorderStatus.cpp.

◆ AudioRecorderStatus() [2/2]

yarp::dev::AudioRecorderStatus::AudioRecorderStatus ( const bool  enabled,
const size_t  current_buffer_size,
const size_t  max_buffer_size
)

Definition at line 26 of file AudioRecorderStatus.cpp.

Member Function Documentation

◆ read() [1/2]

bool yarp::dev::AudioRecorderStatus::read ( yarp::os::ConnectionReader &  reader)
overridevirtual

Read this object from a network connection.

Override this for your particular class.

Parameters
readeran interface to the network connection for reading
Returns
true iff the object is successfully read

Implements yarp::os::Portable.

Definition at line 52 of file AudioRecorderStatus.cpp.

◆ read() [2/2]

bool yarp::dev::AudioRecorderStatus::read ( yarp::os::idl::WireReader &  reader)
overridevirtual

Reimplemented from yarp::os::idl::WirePortable.

Definition at line 37 of file AudioRecorderStatus.cpp.

◆ toString()

std::string yarp::dev::AudioRecorderStatus::toString ( ) const

Definition at line 87 of file AudioRecorderStatus.cpp.

◆ write() [1/2]

bool yarp::dev::AudioRecorderStatus::write ( const yarp::os::idl::WireWriter &  writer) const
overridevirtual

Reimplemented from yarp::os::idl::WirePortable.

Definition at line 62 of file AudioRecorderStatus.cpp.

◆ write() [2/2]

bool yarp::dev::AudioRecorderStatus::write ( yarp::os::ConnectionWriter &  writer) const
overridevirtual

Write this object to a network connection.

Override this for your particular class. Be aware that depending on the nature of the connections a port has, and what protocol they use, and how efficient the YARP implementation is, this method may be called once, twice, or many times, as the result of a single call to Port::write

Parameters
writeran interface to the network connection for writing
Returns
true iff the object is successfully written

Implements yarp::os::Portable.

Definition at line 77 of file AudioRecorderStatus.cpp.

Member Data Documentation

◆ current_buffer_size

size_t yarp::dev::AudioRecorderStatus::current_buffer_size

the size of the audio buffer [samples]

Definition at line 40 of file AudioRecorderStatus.h.

◆ enabled

bool yarp::dev::AudioRecorderStatus::enabled

true if the playback is currently enabled

Definition at line 36 of file AudioRecorderStatus.h.

◆ max_buffer_size

size_t yarp::dev::AudioRecorderStatus::max_buffer_size

the max_size of the audio buffer [samples]

Definition at line 44 of file AudioRecorderStatus.h.

The documentation for this class was generated from the following files:
