yarp::dev::Lidar2DDeviceBase Class Referenceabstract

The Lidar2DDeviceBase class. More...

#include <yarp/dev/Lidar2DDeviceBase.h>

+ Inheritance diagram for yarp::dev::Lidar2DDeviceBase:

Public Member Functions

bool parseConfiguration (yarp::os::Searchable &config)

 Lidar2DDeviceBase ()

bool getRawData (yarp::sig::Vector &data) override
 Get the device measurements. More...

bool getLaserMeasurement (std::vector< LaserMeasurementData > &data) override
 Get the device measurements. More...

bool getDeviceStatus (Device_status &status) override
 get the device status More...

bool getDeviceInfo (std::string &device_info) override
 get the device hardware charactestics More...

bool getDistanceRange (double &min, double &max) override
 get the device detection range More...

bool getScanLimits (double &min, double &max) override
 get the scan angular range. More...

bool getHorizontalResolution (double &step) override
 get the angular step between two measurments. More...

bool getScanRate (double &rate) override
 get the scan rate (scans per seconds) More...

virtual yarp::os::Stamp getLastInputStamp () override
 Return the time stamp relative to the last acquisition. More...

- Public Member Functions inherited from yarp::dev::IRangefinder2D
virtual ~IRangefinder2D ()

virtual bool setDistanceRange (double min, double max)=0
 set the device detection range. More...

virtual bool setScanLimits (double min, double max)=0
 set the scan angular range. More...

virtual bool setHorizontalResolution (double step)=0
 get the angular step between two measurments (if available) More...

virtual bool setScanRate (double rate)=0
 set the scan rate (scans per seconds) More...

- Public Member Functions inherited from yarp::dev::IPreciselyTimed
virtual ~IPreciselyTimed ()


Protected Member Functions

virtual bool updateLidarData ()
 This utility method calls in sequence: grabDataFromHW(), updateTimestamp and applyLimitsOnLaserData(). More...

virtual bool updateTimestamp ()
 By default, it automatically updates the internal timestamp with the yarp time. More...

virtual bool applyLimitsOnLaserData ()
 Apply the limits on the internally stored lidar measurements. More...

virtual bool acquireDataFromHW ()=0
 This method should be implemented by the user, and contain the logic to grab data from the hardware. More...


Protected Attributes

yarp::sig::Vector m_laser_data

yarp::os::Stamp m_timestamp

yarp::dev::IRangefinder2D::Device_status m_device_status

std::mutex m_mutex

std::string m_info

double m_scan_rate

size_t m_sensorsNum

double m_min_angle

double m_max_angle

double m_min_distance

double m_max_distance

double m_resolution

bool m_clip_max_enable

bool m_clip_min_enable

bool m_do_not_clip_and_allow_infinity_enable

std::vector< Range_t > m_range_skip_vector


Additional Inherited Members

- Public Types inherited from yarp::dev::IRangefinder2D
enum  Device_status {
  DEVICE_OK_STANBY = 0 ,
  DEVICE_OK_IN_USE = 1 ,
  DEVICE_GENERAL_ERROR = 2 ,
  DEVICE_TIMEOUT = 3
}


Detailed Description

The Lidar2DDeviceBase class.

This class has been designed to uniform the parsing of lidar yarp devices.

Definition at line 30 of file Lidar2DDeviceBase.h.

Constructor & Destructor Documentation

◆ Lidar2DDeviceBase()

Lidar2DDeviceBase::Lidar2DDeviceBase ( )

Definition at line 92 of file Lidar2DDeviceBase.cpp.

Member Function Documentation

◆ acquireDataFromHW()

virtual bool yarp::dev::Lidar2DDeviceBase::acquireDataFromHW ( )
protectedpure virtual

This method should be implemented by the user, and contain the logic to grab data from the hardware.

Returns
true/false if the method is successful.

Implemented in RpLidar2, LaserFromRosTopic, LaserFromPointCloud, LaserFromExternalPort, LaserFromDepth, and FakeLaser.

◆ applyLimitsOnLaserData()

bool Lidar2DDeviceBase::applyLimitsOnLaserData ( )
protectedvirtual

Apply the limits on the internally stored lidar measurements.

Returns
true/false if the method is successful.

Definition at line 223 of file Lidar2DDeviceBase.cpp.

◆ getDeviceInfo()

bool Lidar2DDeviceBase::getDeviceInfo ( std::string &  device_info)
overridevirtual

get the device hardware charactestics

Parameters
device_infostring containing the device infos
Returns
true/false.

Implements yarp::dev::IRangefinder2D.

Definition at line 67 of file Lidar2DDeviceBase.cpp.

◆ getDeviceStatus()

bool Lidar2DDeviceBase::getDeviceStatus ( Device_status &  status)
overridevirtual

get the device status

Parameters
statusthe device status
Returns
true/false.

Implements yarp::dev::IRangefinder2D.

Definition at line 46 of file Lidar2DDeviceBase.cpp.

◆ getDistanceRange()

bool Lidar2DDeviceBase::getDistanceRange ( double &  min,
double &  max
)
overridevirtual

get the device detection range

Parameters
minthe minimum detection distance
maxthe maximum detection distance
Returns
true/false.

Implements yarp::dev::IRangefinder2D.

Definition at line 31 of file Lidar2DDeviceBase.cpp.

◆ getHorizontalResolution()

bool Lidar2DDeviceBase::getHorizontalResolution ( double &  step)
overridevirtual

get the angular step between two measurments.

Parameters
stepthe angular step between two measurments
Returns
true/false.

Implements yarp::dev::IRangefinder2D.

Definition at line 39 of file Lidar2DDeviceBase.cpp.

◆ getLaserMeasurement()

bool Lidar2DDeviceBase::getLaserMeasurement ( std::vector< LaserMeasurementData > &  data)
overridevirtual

Get the device measurements.

Parameters
dataa vector containing the measurement data, expressed in cartesian/polar format
Returns
true/false..

Implements yarp::dev::IRangefinder2D.

Definition at line 74 of file Lidar2DDeviceBase.cpp.

◆ getLastInputStamp()

yarp::os::Stamp Lidar2DDeviceBase::getLastInputStamp ( )
overridevirtual

Return the time stamp relative to the last acquisition.

Implements yarp::dev::IPreciselyTimed.

Definition at line 265 of file Lidar2DDeviceBase.cpp.

◆ getRawData()

bool Lidar2DDeviceBase::getRawData ( yarp::sig::Vector &  data)
overridevirtual

Get the device measurements.

Parameters
rangesthe vector containing the raw measurement data, as acquired by the device.
Returns
true/false.

Implements yarp::dev::IRangefinder2D.

Definition at line 53 of file Lidar2DDeviceBase.cpp.

◆ getScanLimits()

bool Lidar2DDeviceBase::getScanLimits ( double &  min,
double &  max
)
overridevirtual

get the scan angular range.

Parameters
minstart angle of the scan
maxend angle of the scan
Returns
true/false.

Implements yarp::dev::IRangefinder2D.

Definition at line 23 of file Lidar2DDeviceBase.cpp.

◆ getScanRate()

bool Lidar2DDeviceBase::getScanRate ( double &  rate)
overridevirtual

get the scan rate (scans per seconds)

Parameters
ratethe scan rate
Returns
true/false.

Implements yarp::dev::IRangefinder2D.

Definition at line 60 of file Lidar2DDeviceBase.cpp.

◆ parseConfiguration()

bool Lidar2DDeviceBase::parseConfiguration ( yarp::os::Searchable &  config)

Definition at line 106 of file Lidar2DDeviceBase.cpp.

◆ updateLidarData()

bool Lidar2DDeviceBase::updateLidarData ( )
protectedvirtual

This utility method calls in sequence: grabDataFromHW(), updateTimestamp and applyLimitsOnLaserData().

It is recommended that the device driver implementation calls this method to perform the aforementioned three operations.

Returns
true/false if the methods called internally are all successful

Definition at line 272 of file Lidar2DDeviceBase.cpp.

◆ updateTimestamp()

bool Lidar2DDeviceBase::updateTimestamp ( )
protectedvirtual

By default, it automatically updates the internal timestamp with the yarp time.

It can be redefined by the user if the timestamp source is for example the hardware device.

Returns
true/false if the update is successful.

Definition at line 287 of file Lidar2DDeviceBase.cpp.

Member Data Documentation

◆ m_clip_max_enable

bool yarp::dev::Lidar2DDeviceBase::m_clip_max_enable
protected

Definition at line 51 of file Lidar2DDeviceBase.h.

◆ m_clip_min_enable

bool yarp::dev::Lidar2DDeviceBase::m_clip_min_enable
protected

Definition at line 52 of file Lidar2DDeviceBase.h.

◆ m_device_status

yarp::dev::IRangefinder2D::Device_status yarp::dev::Lidar2DDeviceBase::m_device_status
protected

Definition at line 38 of file Lidar2DDeviceBase.h.

◆ m_do_not_clip_and_allow_infinity_enable

bool yarp::dev::Lidar2DDeviceBase::m_do_not_clip_and_allow_infinity_enable
protected

Definition at line 53 of file Lidar2DDeviceBase.h.

◆ m_info

std::string yarp::dev::Lidar2DDeviceBase::m_info
protected

Definition at line 43 of file Lidar2DDeviceBase.h.

◆ m_laser_data

yarp::sig::Vector yarp::dev::Lidar2DDeviceBase::m_laser_data
protected

Definition at line 36 of file Lidar2DDeviceBase.h.

◆ m_max_angle

double yarp::dev::Lidar2DDeviceBase::m_max_angle
protected

Definition at line 47 of file Lidar2DDeviceBase.h.

◆ m_max_distance

double yarp::dev::Lidar2DDeviceBase::m_max_distance
protected

Definition at line 49 of file Lidar2DDeviceBase.h.

◆ m_min_angle

double yarp::dev::Lidar2DDeviceBase::m_min_angle
protected

Definition at line 46 of file Lidar2DDeviceBase.h.

◆ m_min_distance

double yarp::dev::Lidar2DDeviceBase::m_min_distance
protected

Definition at line 48 of file Lidar2DDeviceBase.h.

◆ m_mutex

std::mutex yarp::dev::Lidar2DDeviceBase::m_mutex
protected

Definition at line 39 of file Lidar2DDeviceBase.h.

◆ m_range_skip_vector

std::vector<Range_t> yarp::dev::Lidar2DDeviceBase::m_range_skip_vector
protected

Definition at line 54 of file Lidar2DDeviceBase.h.

◆ m_resolution

double yarp::dev::Lidar2DDeviceBase::m_resolution
protected

Definition at line 50 of file Lidar2DDeviceBase.h.

◆ m_scan_rate

double yarp::dev::Lidar2DDeviceBase::m_scan_rate
protected

Definition at line 44 of file Lidar2DDeviceBase.h.

◆ m_sensorsNum

size_t yarp::dev::Lidar2DDeviceBase::m_sensorsNum
protected

Definition at line 45 of file Lidar2DDeviceBase.h.

◆ m_timestamp

yarp::os::Stamp yarp::dev::Lidar2DDeviceBase::m_timestamp
protected

Definition at line 37 of file Lidar2DDeviceBase.h.

The documentation for this class was generated from the following files:
