constants.h File Reference

File containing constans used in FfmpegPortmonitor.cpp. More...

#include <string>
#include <vector>
#include <map>
#include <libavcodec/avcodec.h>
#include <yarp/sig/Image.h>

Include dependency graph for constants.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Variables
static const std::vector< std::string >	FFMPEGPORTMONITOR_IGNORE_PARAMS
	This vector contains all parameters that have to be ignored while parsing command line string. More...
static const std::string	FFMPEGPORTMONITOR_CL_CODEC_KEY = "codec"
	This string is the "key" value for the codec parameter. More...
static const std::vector< std::string >	FFMPEGPORTMONITOR_CL_CODECS
	This vector contains the only accepted values for the command line parameter "codec". More...
static const std::vector< int >	FFMPEGPORTMONITOR_CODE_CODECS
	This vector contains the codec ids corresponding to the codecs of the FFMPEGPORTMONITOR_CL_CODECS vector. More...
static std::map< int, int >	FFMPEGPORTMONITOR_PIXELMAP
	This structure maps YARP pixel format codec into Ffmpeg pixel format codes. More...
static std::map< int, int >	FFMPEGPORTMONITOR_CODECPIXELMAP
	This structure maps Ffmpeg video codecs with their needed Ffmpeg pixel format code. More...

Detailed Description

File containing constans used in FfmpegPortmonitor.cpp.

Author

Giulia Martino, Fabio Valla

Version

1.0

Date

2021-01-04

Definition in file constants.h.

Variable Documentation

FFMPEGPORTMONITOR_CL_CODEC_KEY

const std::string FFMPEGPORTMONITOR_CL_CODEC_KEY = "codec"

static

This string is the "key" value for the codec parameter.

Definition at line 48 of file constants.h.

FFMPEGPORTMONITOR_CL_CODECS

const std::vector<std::string> FFMPEGPORTMONITOR_CL_CODECS

static

Initial value:

{
    "mpeg2video",
    "h264",
    "h265"
}

This vector contains the only accepted values for the command line parameter "codec".

Definition at line 54 of file constants.h.

FFMPEGPORTMONITOR_CODE_CODECS

const std::vector<int> FFMPEGPORTMONITOR_CODE_CODECS

static

Initial value:

{
    AV_CODEC_ID_MPEG2VIDEO,
    AV_CODEC_ID_H264,
    AV_CODEC_ID_H265
}

This vector contains the codec ids corresponding to the codecs of the FFMPEGPORTMONITOR_CL_CODECS vector.

Definition at line 64 of file constants.h.

FFMPEGPORTMONITOR_CODECPIXELMAP

std::map<int, int> FFMPEGPORTMONITOR_CODECPIXELMAP

static

Initial value:

= {
    { AV_CODEC_ID_H264, AV_PIX_FMT_YUV420P },
    { AV_CODEC_ID_H265, AV_PIX_FMT_YUV420P },
    { AV_CODEC_ID_MPEG2VIDEO, AV_PIX_FMT_YUV420P }
}

This structure maps Ffmpeg video codecs with their needed Ffmpeg pixel format code.

Definition at line 86 of file constants.h.

FFMPEGPORTMONITOR_IGNORE_PARAMS

const std::vector<std::string> FFMPEGPORTMONITOR_IGNORE_PARAMS

static

Initial value:

{
    "tcp",
    "fast_tcp",
    "udp",
    "send.portmonitor",
    "recv.portmonitor",
    "file.image_compression_ffmpeg",
    "type.dll"
}

This vector contains all parameters that have to be ignored while parsing command line string.

Definition at line 34 of file constants.h.

FFMPEGPORTMONITOR_PIXELMAP

std::map<int, int> FFMPEGPORTMONITOR_PIXELMAP

static

Initial value:

= {
  { VOCAB_PIXEL_RGB, AV_PIX_FMT_RGB24 },
  { VOCAB_PIXEL_RGBA, AV_PIX_FMT_RGBA },
  { VOCAB_PIXEL_BGR, AV_PIX_FMT_BGR24 },
  { VOCAB_PIXEL_BGRA, AV_PIX_FMT_BGRA },
  { VOCAB_PIXEL_YUV_420, AV_PIX_FMT_YUV420P }
}

This structure maps YARP pixel format codec into Ffmpeg pixel format codes.

Definition at line 74 of file constants.h.
