yarp::dev::IAudioRender Class Reference

#include <yarp/dev/IAudioRender.h>

Inheritance diagram for yarp::dev::IAudioRender:

Public Member Functions
virtual	~IAudioRender ()
	Destructor. More...
virtual bool	renderSound (const yarp::sig::Sound &sound)=0
	Render a sound using a device (i.e. More...
virtual bool	startPlayback ()=0
	Start the playback. More...
virtual bool	stopPlayback ()=0
	Stop the playback. More...
virtual bool	isPlaying (bool &playback_enabled)=0
	Check if the playback has been enabled (e.g. More...
virtual bool	getPlaybackAudioBufferMaxSize (yarp::dev::AudioBufferSize &size)=0
virtual bool	getPlaybackAudioBufferCurrentSize (yarp::dev::AudioBufferSize &size)=0
virtual bool	resetPlaybackAudioBuffer ()=0
virtual bool	setSWGain (double gain)=0
	Sets a software gain for the played audio. More...
virtual bool	setHWGain (double gain)=0
	Sets the hardware gain of the playback device (if supported by the hardware) More...

Detailed Description

Definition at line 17 of file IAudioRender.h.

Constructor & Destructor Documentation

~IAudioRender()

yarp::dev::IAudioRender::~IAudioRender ( )

virtualdefault

Destructor.

Member Function Documentation

getPlaybackAudioBufferCurrentSize()

virtual bool yarp::dev::IAudioRender::getPlaybackAudioBufferCurrentSize ( yarp::dev::AudioBufferSize &  size )

pure virtual

Implemented in yarp::dev::AudioPlayerDeviceBase, and PortAudioDeviceDriver.

getPlaybackAudioBufferMaxSize()

virtual bool yarp::dev::IAudioRender::getPlaybackAudioBufferMaxSize ( yarp::dev::AudioBufferSize &  size )

pure virtual

Implemented in yarp::dev::AudioPlayerDeviceBase, and PortAudioDeviceDriver.

isPlaying()

virtual bool yarp::dev::IAudioRender::isPlaying ( bool &  playback_enabled )

pure virtual

Check if the playback has been enabled (e.g.

via startPlayback()/stopPlayback())

Parameters

playback_enabled

the status of the device

Returns

true/false upon success/failure

Implemented in yarp::dev::AudioPlayerDeviceBase, and PortAudioDeviceDriver.

renderSound()

virtual bool yarp::dev::IAudioRender::renderSound ( const yarp::sig::Sound &  sound )

pure virtual

Render a sound using a device (i.e.

send it to the speakers).

Parameters

sound

the sound to be rendered

Returns

true/false upon success/failure

Implemented in yarp::dev::AudioPlayerDeviceBase, PortAudioDeviceDriver, and audioToFileDevice.

resetPlaybackAudioBuffer()

virtual bool yarp::dev::IAudioRender::resetPlaybackAudioBuffer ( )

pure virtual

Implemented in yarp::dev::AudioPlayerDeviceBase, and PortAudioDeviceDriver.

setHWGain()

virtual bool yarp::dev::IAudioRender::setHWGain ( double  gain )

pure virtual

Sets the hardware gain of the playback device (if supported by the hardware)

Parameters

gain	the audio gain (1.0 is the default value)

Returns

true/false upon success/failure

Implemented in PortAudioPlayerDeviceDriver, PortAudioDeviceDriver, fakeSpeaker, and audioToFileDevice.

setSWGain()

virtual bool yarp::dev::IAudioRender::setSWGain ( double  gain )

pure virtual

Sets a software gain for the played audio.

Parameters

gain	the audio gain (1.0 is the default value)

Returns

true/false upon success/failure

Implemented in yarp::dev::AudioPlayerDeviceBase, and PortAudioDeviceDriver.

startPlayback()

virtual bool yarp::dev::IAudioRender::startPlayback ( )

pure virtual

Start the playback.

Returns

true/false upon success/failure

Implemented in yarp::dev::AudioPlayerDeviceBase, PortAudioPlayerDeviceDriver, PortAudioDeviceDriver, and audioToFileDevice.

stopPlayback()

virtual bool yarp::dev::IAudioRender::stopPlayback ( )

pure virtual

Stop the playback.

Returns

true/false upon success/failure

Implemented in yarp::dev::AudioPlayerDeviceBase, PortAudioPlayerDeviceDriver, PortAudioDeviceDriver, and audioToFileDevice.

---

The documentation for this class was generated from the following files:

• src/libYARP_dev/src/yarp/dev/IAudioRender.h
• src/libYARP_dev/src/yarp/dev/IAudioRender.cpp
